DA-TM4200 INSTALLATION MANUAL

This manual is intended for users of the DA-TM4200 wall mounting

bracket. It includes instructions for mounting the DA-TM4200 wall

mounting bracket to a wall.

• This bracket is intended to be used with a specic

model of camera. Do not use it with other models of

cameras except for those approved by the dealer or

distributor.

• This installation should be performed by a qualied

service personnel in conformance to all local codes.

• You may need to reinforce the wall. If the wall is not

strong enough to support the camera, the camera

may fall.

• Do not use this product for other purposes.

Mounting

Mount the bracket to the wall as follows:

1 Insert cables from external devices, network and

power adapter to the sponge and bracket.

2 Mount bracket to the wall by using the provided

anchors and screws.

Bracket

Wall Hole

Connect your camera to the bracket as follows:

3 Screw the camera body onto bracket.

Bracket

Camera

body

IDIS Co., Ltd.

For more information, please visit www.idisglobal.com

4 Secure the top cover to the body by turning it colckwise.

Camera

body

Camera

Top Cover

5 Turn on power.

Dimension

Unit: mm (inch)

Ver.1.0
