Assembly Instructions: (Monroe)7041-M1L

IMPORTANT:

•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important notes above. Shut off the

poweratthecircuitbreakerandcompletelyremovetheoldxturefromtheceiling,including

theoldmountingstrap.

1.Fromthepartsbagremovethemountingstrapassembly.Oneendofnipple(F)shouldbe

attachedtomountingstrap(A)withwasherandhexnut(CandD)inplace.Theotherend

shouldhavecanopyloop(H)attached.Attachmountingstrap(A)tothejunctionboxusing

mountingscrews(B)andascrewdriver.Tightensecurely.

2. Unscrew canopy loop collar (I) from canopy loop (H). Pass canopy (G) over the mounted

canopylooptotesttheheight.Approximatelyhalfofthecanopyloop’sexteriorthreadsshould

beexposed,andthecanopyloopcollarshouldtsnuglyontothecanopyloop.Remove

canopy(G)andadjusttheheightofnipple(F)andcanopyloop(H)untilthedesiredheightis

reached.

ASSEMBLING THE FIXTURE

3.Decorativerod(N)isonthexture’swires,butnotattachedtothexture.Hookthebottom

of decorative rod (N) into top loop (L) and pull the wires until taut.

4.Bymeasuring,determinethecorrectnumberofchainlinksneededforproperhanging

height.Ifnecessary,useapairofplierstoopenandremoveanyexcesschain.

5.Attachchainconnectors(K)toeachendofchain(J)beforeattachingoneendofthechain

connector/chain to the top of decorative rod (N). Close the chain connector. Connect the

other chain connector (K) to canopy loop (H).

6.Passthexture’swiresupthroughchain(J)(everythreelinksorso).Slidecanopyloop

collar (I) and canopy (G) onto the chain/wire.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

For Customer Service, please

contact the place of purchase.

CONNECTING THE WIRES

7.Haveanassistantsupporttheweightofthexturewhilecompletingthewiring.Cutaway

excesswire.Threadthexture’swiresthroughcanopyloop(H)andnipple(F).Attachthe

xture’swirestothepowersupplywiresfromthejunctionbox.Connectblacktoblack(or

smooth);whitetowhite(orribbed);groundtoground(greenorcopper).Twisttheendsofthe

wirepairstogether,andthentwistonawireconnector.Makesurealltwistsareinthesame

direction.Ifthereisnogroundwire(greenorcopper)comingfromthejunctionbox,locate

groundscrew(E)onmountingstrap(A)andwrapthexture’sgroundwirearoundthegreen

groundscrew(E).Useascrewdrivertosecuregroundscrew(E)ontothemountingbracket.

Tuckallwiresneatlyintothejunctionbox.

FINISHING THE INSTALLATION

8.Pushcanopy(G)uptotheceilingand

slide canopy loop collar (I) up beneath

thecanopy.Tightlythreadcanopyloop

collar (I) onto canopy loop (H) to secure

canopy (G) in place.

House Wires

Fixture Wires

Hot

How to Identify the Fixture’s Wires

HotNeutralGround

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

9.Slideglassshade(P)oversocket(M)andsecureinplacewithsocketcover(O).

10.

Installalightbulb(notprovided)inaccordancewiththexture’sspecications.Donotexceedthemaximumrecommended

wattage.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
