IMPORTANT:
•ALLINSTALLATIONWORKSHOULDBEDONEBYACCREDITEDPROFESSIONAL.
•SHUTOFFPOWERSUPPLYATFUSEORCIRCUITBREAKER!
•USEONLYTHESPECIFIEDBULBS.DONOTEXCEEDTHEMAXIMUMWATTAGE!
CONNECTING THE WIRES
4.Attachthexture’swirestothepowersupplywiresfromthe
junctionbox.Connectblacktoblack(orsmooth);whitetowhite(or
ribbed);groundtoground(greenorcopper).Twisttheendsofthe
wirepairstogether,thentwistonawireconnector.Makesureall
twistsareinthesamedirection.Ifthereisnogroundwire(greenor
copper)fromthejunctionbox,locategroundscrew(E)onmounting
strap(B)andwrapthexture’sgroundwirearoundthegreenground
screw(E).Useascrewdrivertosecuregroundscrew(E)ontothe
mountingbracket.Tuckallwiresneatlyintothejunctionbox.
For Customer Service, please
contact the place of purchase.
A:ssemblyInstructions(Manhattan)2243-BA1/BA2/BA3/BA4
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
PREPARING FOR INSTALLATION
Remove all of the contents from the carton. See the important
notes above. Shut off the power at the circuit breaker and
completely remove the old xture from the wall, including the old
mounting strap.
1.Mountingstrap(B)containsseveralpairsofthreadedholesand
twoofmountingscrews(D).Youmayneedtotightenhexnuts(C)
thatholdthescrewsinplace.
2.Placemountingstrap(B)uptoyourjunctionbox.Placebackplate
(F)overthemountingstrapliningupmountingscrews(D)withthe
holesinbackplate(F).Thiswillallowyoutoensurethatyouare
hangingthexturestraight.
3.Pullthehousewiresthroughthecenterofmountingstrap(B).
Securemountingstrap(B)tothejunctionboxwithmountingscrews
(A)andascrewdriver.Tightenthescrewssecurely.
House Wires
Fixture Wires
Hot
How to Identify the Fixture’s Wires
HotNeutralGround
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
FINISHING THE INSTALLATION
5.Placebackplate(F)overmountingstrap(B)sothatmountingscrews(D)protrudethroughtheholesinbackplate(F).Securethe
backplatetothemountingstrapwithdecorativenuts(J).Twistuntilthebackplateofthextureissnugagainstthewall.
6.Slideglass(I)overthesocket(G)andsecureinplacewithsocketcover(H).
7.Installlightbulb(notincluded)inaccordancewiththexture’sspecications.Donotexceedthemaximumrecommendedwattage.
Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
J
B
A
D
C
E
G
H
I
F
