Die EX-11092-2 ist eine USB 3.2 Gen 1 PCIe Karte. Sie ist mit zwei externen Buchsen ausge-

stattet, die jeweils 900mA Strom zu Verfügung stellen. Die EX2 unterstützt die volle -11092-

Leistung von 900mA an beiden externen Buchsen ohne das Sie zusätzlichen Strom vom PC-

Netzteil benötigen. Sie unterstützt alle PCIe Slots von x1 bis x16. Der PCIExpress Bus unter--

stützt optimal die Leistung des schnellen Renesas Chipsatz. Die EX2 gewährleistet so -11092-

eine sichere Datenübertragung und exzellente Performance von bis zu 5Gbit pro Sekunde! Sie

unterstützt alle USB Anschlüsse von 1.1 bis 3.2. Zusätzlich bietet die EX2 Ihnen die -11092-

Möglichkeit das USB Kabel an die UBS Buchsen der Karte zu verschrauben.

Kompatibilität:PCIExpress p1-x1 bis x16-

Betriebssysteme:Windows XP / Vista / 7 / 8.x / 10 / 11 / Server 20xx / Linux / Mac

Anschlüsse:2x USB 3.2 Gen 1 ABuchse (verschraubbar), 1x 4Pin Molex Power --

Anschluss

Lieferumfang:2, Low Profile Bügel, Treiber CD, AnleitungEX-11092-

Zertifikate:

1

BESCHREIBUNG & TECHNISCHE DATEN

AUFBAU

Anleitun

Vers. 1.5 / 26.02.24

E1109

ANSCHLÜSSE & JUMPEREINSTELLUNG

2x USB 3.2 Gen 1 ABuchse (verschraubbar)-

USB 3.2 Gen 1 Buchse:

USB 2.0 Pins‘

PinSignal

1VCC

2DATA-

3DATA+

4GND

USB 3.2 Pins‘

PinSignal

5SSTX+

6SSTX-

7GND

8SSRX+

9SSRX-

4Pin Molex Power Anschluss für PCNetzteil--

DRIVER INSTALLATION

CHECK INSTALLED DRIVER

Open the >Device manager<. Now you should see at „USB-Controller“ the following new entry's:

If you see this or a similar information the device is installed correctly.

Windows 8.x / 10 / 11 / Server 2012R2 & 2016 & 2019 & 2022

After the hardware installation, the operating system will recognize the device automatically and

install the drivers.

CHECK INSTALLED DRIVER

Open the >Device manager<. Now you should see at „USB-Controller“ the following new entry's:

If you see this or a similar information the device is installed correctly.

Linux / Mac

After the hardware installation, the operating system will recognize the device automatically and

install the drivers.

JP1:

Jumper zur Auswahl

der Stromquelle

(Netzteil oder

PCIExpress Bus)-

HARDWAREINSTALLATION

DRIVER INSTALLATION

Please note the following installation instructions. Because there are large differences between the

PC’s, we can give you only a general installation instructions for the EX-11092-2. Please refer your

computers reference manual whenever in doubt.’

1.Turn off the power to your computer and any other connected peripherals.

2.Remove the mounting screws located at the rear and/or sides panels of your Computer and

gently slide the cover off.

3.Locate an available PCI-Express expansion slot and insert the card. Make sure that the card

is plugged in correctly.

4. If necessary please install now the external power supply to the card.

5.Then attach the card with a screw to the rear panel of the computer.

6.Gently replace your computers cover and the mounting screws.’

Windows XP / Vista / 7 / Server 2003 & 2008R2

After starting Windows is recognizes a new . Now ““USB (Universal Serial Bus)Controller-

insert the Driver CD into your CDROM drive (e.g. drive D:) and start the which is -„“ setup

located in the folder (see picture):„“ USB 3.0/RENESAS/uDP720201_202

Follow the installation instructions and complete the installation.

Windows will now install automatically you right driver for your particular operating system. After

the installation the operating system detects the card and automatically install them.

CONNECTORS

4Pin Molex Power Connector :-

1 +12V2 GND3 GND4 +5V

If JP1 is set to AUX, the connector must be connected to

the power connector from the PC power supply.

Please make sure you connect the plug in the right

direction!

Attention! Never connect or release the plug while the

PC power is on!

INT = (Factory Setting)Power 900mA from PCIExpress BUS -

AUX = Power 900mA from PC power supply

(For safe direct power from PC power supply to provide sufficient power

for devices with high power consumption)

The 4Pin Molex Power Connector must then be connected to the -

PC power supply!

JP1:

INT

AUX
