2.2 Panel Cut-Out

2. General Descr�pt�on

2.1 Front V�ew and D�mens�ons of EPM-3790 Un�t

EPM-3790N 77x35 DIN S�ze

Control Panel For V/F Speed Controller

Instruct�on Manual. ENG EPM-3790-N 01 V03 07/23

Operat�ng Temperature :0 to 50 °C

Max. Operat�ng Hum�d�ty :90 Rh (non-condens�ng)

:Alt�tudeUp to 2000m

Forb�dden Cond�t�ons:

Corros�ve atmosphere

Explos�ve atmosphere

Home appl�cat�ons (The un�t �s only for �ndustr�al appl�cat�ons)

1.2 General Spec�f�cat�ons

1 Preface

2

1.1 Operat�ng Cond�t�ons

341615

1314

EPM-3790N

Power Supply Input

D�g�tal Input

110 mm / 4.33 �nch (m�n)

50 mm / 1.97 �nch (m�n)

29 mm / 1.14 �nch

71 mm / 2.79 �nch

1.3 Installat�on

1.4 Warranty

1.5 Ma�ntenance

1.6 Manufacturer

Mount�ng Clamp

Panel surface

Max�mum th�ckness 15 mm / 0.59 �nch

76 mm / 3 �nch

6 mm / 0.24 �nch

34,5 mm / 1.36 �nch

65 mm / 2.56 �nch

Error Input

EPM-3790N

SET

9. Order�ng Informat�on

ABCDEFGHI/

/

U

VWZ/

/

000100

EPM-3790N

000

(77 x 35 DIN S�ze)

RS-485 Commun�cat�on Interface

1.RS-485 Module

2. PROKEY Programm�ng Module

Your technology partner

www.emkoelektronik.com.tr



EPM-3790N

7. Motor Start / Stop Operat�on

EPM-3790N

SET

i

8. Spes�f�cat�ons

Dev�ce Type

Hous�ng & Mount�ng

Protect�on Class

We�ght

Env�ronmental Rat�ng

Storage / Operat�ng Temperature

Storage / Operat�ng Hum�d�ty

Installat�on

Overvoltage Category

Pollut�on Degree

Scale

Analogue Output

Resolut�on

Supply Voltage and Power

D�splay

LEDs

: Control Panel For V/F Speed Controller

: 77mm x 35mm x 62.5mm Plast�c hous�ng for panel

Mount�ng. Panel cut-out �s 71x29mm.

: Approx�mately 200 grams

: Standard, �ndoor at an alt�tude of less than 2000 meters

w�th none-condens�ng hum�d�ty.

: F�xed Installat�on

: II.

: II. Off�ce or workplace, none conduct�ve pollut�on

: Between -1999 and 9999

: 12 b�ts

: 10 mm red 4 d�g�ts LED

:Compl�ances

: -40 C to +85 C / 0 C to +50 C

: 90 % max. (None condens�ng)

: NEMA 4X (IP65 at front, IP20 at rear).

: 0/2...10VZ Voltage Output (Max.10mA) or

0/4...20mAZ Current Output

D�g�tal Output

: Forward D�rect�on Output (Max. 5mA@30V)

Reverse D�rect�on Output (Max. 5mA@30V)

D�g�tal Input

: Error Input (Max. 5mA@30VZ)

M�n. H�gh Level 7VZ )

Max. Low Level 5VZ )

Fluctuat�on

: 30 mV

0

9. Opt�onal Accessor�es

SET

Standard

D�g�tal Output

In accordance w�th the WEEE regulat�on.

Please leave the dev�ce to a recycl�ng po�nt for electr�cal dev�ces.

: 230VV(±%15) 50/60Hz - 2.5VA

: 115VV(±%15) 50/60Hz - 2.5VA

: 24VV(±%15) 50/60Hz - 2.5VA

: 24VW(±%15) 50/60Hz - 2.5VA

: 10 - 30VZ- 2.5W

-4 D�g�ts D�splay

-Adjustable dec�mal po�nt

-Set value low l�m�t and set value h�gh l�m�t boundar�es

-Adjustable ramp up and ramp down t�me

-Eas�ly adjustable set value from front panel

-Conf�gurable d�splay scale between -1999 and 9999

-Forward, Reverse d�rect�on outputs and error �nput for V/F Speed

Controller

-0/2...10V Z Voltage output or 0/4...20mA Z Current output

(Itmust be spec�f�ed �n order.)

-Password protect�on for programm�ng and sett�ngs sect�ons

EPM-3790N 77x35 DIN S�ze

Control Panel For V/F Speed Controller

EPM-3790-N ser�es un�ts are des�gned for controll�ng the speed and d�rect�on of the motor as

a control panel for V/F Speed Controllers �n �ndustry. They can be used �n many appl�cat�ons

w�th the�r easy use and operat�on w�th the�r ramp propert�es.

Un�versal SupplyInput

230V V (±%15) 50/60Hz

Opt�onal Supply Input

115V V (±%15) 50/60Hz

24V V (±%15) 50/60Hz

24V W (±%15) 50/60Hz

10 - 30V Z

Forward D�rect�on Output

Reverse D�rect�on Output

Analogue Output

(0/2...10V Z)

Analogue Output

(0/4...20mA Z)

Reference Speed for

V/F Speed Controller

Front Panel

IP65 protect�on

NEMA 4X

Before beg�nn�ng �nstallat�on of th�s product, please read the �nstruct�on manual and

warn�ngs below carefully.

c

Th�s package conta�ns

- A dev�ce un�t

- Two p�eces of mount�ng clamps

- An �nstruct�on manual

A v�sual �nspect�on of th�s product for poss�ble damage occured dur�ng sh�pment �s recommended before

�nstallat�on. It �s your respons�b�l�ty to ensure that qual�f�ed mechan�cal and electr�cal techn�c�ans �nstall th�s product.

If there �s danger of ser�ous acc�dent result�ng from a fa�lure or defect �n th�s un�t, power off the system and the

electr�cal connect�on of the dev�ce from the system.

The un�t �s normally suppl�ed w�thout a power supply sw�tch or a fuse. Use power sw�tch and fuse as requ�red.

Be sure to use the rated power supply voltage to protect the un�t aga�nst damage and to prevent fa�lure.

Keep the power off unt�l all of the w�r�ng �s completed so that electr�c shock and trouble w�th the un�t can be

prevented.

Never attempt to d�sassemble, mod�fy or repa�r th�s un�t. Tamper�ng w�th the un�t may results �n malfunct�on, electr�c

shock or f�re.

Do not use the un�t �n combust�ble or explos�ve gaseous atmospheres.

Dur�ng the equ�pment �s putted �n hole on the metal panel wh�le mechan�cal �nstallat�on some metal burrs can cause

�njury on hands, you must be careful.

Installat�on of the product on a system must be done w�th the prov�ded f�x�ng clamps. Do not attempt to �nstall the

dev�ce w�th �nappropr�ate f�x�ng clamps. Make sure to keep the dev�ce steady dur�ng the �nstallat�on.

It �s your respons�b�l�ty �f th�s equ�pment �s used �n a manner not spec�f�ed �n th�s �nstruct�on manual.

EMKO Elektron�k warrants that the equ�pment del�vered �s free from defects �n mater�al and workmansh�p. Th�s warranty �s

prov�ded for a per�od of two years. The warranty per�od starts from the del�very date. Th�s warranty �s �n force �f duty and

respons�b�l�t�es wh�ch are determ�ned �n warranty document and �nstruct�on manual performs by the customer completely.

Repa�rs should only be performed by tra�ned and spec�al�zed personnel. Cut power to the dev�ce before access�ng �nternal

parts. Do not clean the case w�th hydrocarbon-based solvents (Petrol, Tr�chlorethylene etc.). Use of these solvents can

reduce the mechan�cal rel�ab�l�ty of the dev�ce. Use a cloth dampened �n ethyl alcohol or water to clean the external plast�c

case.

Manufacturer Informat�on:

Emko Elektron�k Sanay� ve T�caret A.Ş.

Bursa Organ�ze Sanay� Bölges�, (Feth�ye OSB Mah.)

Al� Osman Sönmez Bulvarı, 2. Sokak, No:3 16215

BURSA/TÜRKİYE

Phone : +90 224 261 1900

Fax

: +90 224 261 1912

Repa�r and Ma�ntenance Serv�ce Informat�on:

Emko Elektron�k Sanay� ve T�caret A.Ş.

Bursa Organ�ze Sanay� Bölges�, (Feth�ye OSB Mah.)

Al� Osman Sönmez Bulvarı, 2. Sokak, No:3 16215

BURSA/TÜRKİYE

Phone : +90 224 261 1900

Fax : +90 224 261 1912

A

PowerSupply

2

3

5

8

4

9

Customer Spec�f�ed

24VW (±%15) 50/60Hz - 2.5VA

24VV (±%15) 50/60Hz - 2.5VA

115VV (±%15) 50/60Hz - 2.5VA

230VV (±%15) 50/60Hz - 2.5VA

10 - 30V Z - 2.5W

5

Voltage Output (0/2...10V Z max. 10 mA)

Output

E

Current Output (0/4...20mA Z)

4

All order �nformat�on of EPM-3790N un�ts are g�ven on the table above. User may form

appropr�ate dev�ce conf�gurat�on from �nformat�on and codes that at the table and convert �t

to the order�ng codes. F�rstly, supply voltage then other spec�f�cat�ons must be determ�ned.

Please f�ll the order code blanks accord�ng to your needs. Please contact us, �f your needs

are out of the standards.

Please set the parameters accord�ng to des�red cond�t�ons before operat�ng the dev�ce.

Improperly conf�gured dev�ce may cause hazard.

Module for upload�ng and download�ng

the user parameters

V Symbol means Vac,

Z Symbol means Vdc,

Please don't d�spose the dev�ce along w�th other waste at the end of �ts serv�ce l�fe.

Thank you for your �nterest �n EMKO Elektron�k

products. In order to download a more deta�led vers�on

of th�s manual, please v�s�t us at our webs�te.

: (red), (red), (red), (red), (green), (green)

When Start/Stop button �s pressed, Set value �s seen on d�splay, Start led l�ghts on, selected

d�g�tal output �s be�ng act�ve and analogue output starts to �ncrease from the set low l�m�t

value to set value dur�ng Tup(sec) t�me w�th ramp.

Wh�le the motor �s runn�ng �f Start/Stop button �s pressed aga�n set low l�m�t value �s seen on

d�splay, Start led l�ghts off, analogue output starts to decrease from set value to set low l�m�t

value dur�ng Tdown(sec) t�me. When analogue output �s equal to set low l�m�t value selected

d�g�tal output �s be�ng �nact�ve.

It�sval�d,�fthedev�cetype0/2...10V

It�sval�d,�fthedev�cetype0/4...20mA

Z

Z

analogueoutput.

analogueoutput.

Ifnooperat�on�sperformed�nprogramm�ngmodefor20

seconds,dev�ceturnstooperat�onscreenautomat�cally.

(1)

(2)

Error Detect�on for

V/F Speed Controller

Forward, Reverse D�rect�on

Control for V/F Speed Controller

Protect�on Aga�nst

Mechan�cal Impacts : 1Joule (IK06)

,

,


