GYRO LED
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
Introduction:
The Gyro LED is a 7 channel DMX intelligent scanner unit. The Gyro LED has 3 operating modes; sound
active mode, auto program mode, or it can be controlled by a DMX controller. The unit can be run as a stand
alone unit or in a Master/Slave configuration. This unit has been tested at the factory, there is no assembly
required. The unit is ready to be plugged in to a power outlet. To enhance the beams effects you can use a
fog machine. This unit looks good in pairs.
CAUTION! Please read and understand these instructions before installing or operating this unit.
SPECIFICATIONS:
Model: Gyro LED
LED: 1 x 25W LED
Weight: 9.4lbs./ 4.3kgs.
Size: 12.75” (H) x 6” (W) x
5” (L)
Fuse: 2 Amp
Power Consumption: 50W
Supply Voltage: 110V-240V 50/60Hz
Working Position: Any Safe position
Duty Cycle: None
DMX Channels: 7 DMX Channels
Gobos: 11 plus Spot
Colors: 8 Colors + White
Warranty: 1 Year
CAUTION! Please read and
understand these instructions
before installing or operating
this unit.
Fuse Replacement: Locate and remove
the unit’s power cord. Once the cord has
been removed located the fuse holder
located inside the power socket. Insert
a flat-head screw driver into the power
socket and gently pry out the fuse holder.
Remove the bad fuse and replace with a
new one. The fuse holder has a built-in
socket for a spare fuse be sure not to
confuse the spare fuse with active fuse.
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
MENUS: To access these menus you must press the ESC button twice and then press the UP or
DOWN buttons until you nd the specic menu you are looking for.
ADDR: At this menu you can set the DMX address. Press the Enter button, and the “A” will start
ashing. Press the UP or Down buttons to nd your desired address. When you have found your
desired address press the Enter button to set it.
SOUN (Sound Active): In this menu you can activate Sound Active mode. Using the Up button
scroll to “SOUN” and press Enter. Either “MAST” (Master in sound mode) or “ALON” (Stand Alone
unit in sound mode) will be displayed. Use the Up and Down buttons toggle between the two modes
and press Enter to make your selection.
AUTO (Auto Program): In this menu you can activate the auto program mode. Using the Up or
Down buttons scroll to “AUTO” and press Enter. Either “MAST” (Master in Auto mode) or “ALON”
(Stand Alone unit in Auto mode) will be displayed. Use the Up and Down buttons toggle between the
two modes and press Enter to make your selection.
RPAN (Reverse Pan): In this menu you can reverse the Pan function. Using the Up button scroll to
“RPAN” and press Enter. Press the Up button until “On” is displayed, and press Enter. This func-
tion works better when you have two units connected in a Master/Slave setup. Have one unit set to
reverse Pan and the other unit left in normal Pan.
RTIL ( Reverse Tilt): In this menu you can reverse the Tilt function. Using the Up button scroll to
“RTIL” and press Enter. Press the Up button until “On” is displayed, and press Enter. This function
works better when you have two units connected in a Master/Slave setup. Have one unit set to re-
verse Tilt and the other unit left in normal Tilt.
RDIS (Display): In this menu you can “ip” the display 180°. Using the Up button scroll to “RDIS”
and press Enter. Either “ON” or “OFF” will now be displayed. If you want to “ip” the display press
the Up button so that “ON” is displayed, and press Enter.
REST (Reset): In this menu you can activate reset function. Using the Up button scroll to “REST”
and press Enter. The unit will now begin to reset.
LOAD: In this menu you can activate reset function. Using the Up button scroll to “LOAD” and press
Enter. The unit will now begin to reset.
UNIVERSAL DMX CONTROL: This unit allows you to use any universal DMX- controller to control head 512
movement, the color wheel, the gobo wheel, and the shutter (strobe). A DMX controller allows you to create
unique programs tailored to your individual needs. Follow the set-up specifications that are included with
your DMX controller.
1. The Gyro LED is a 7 Channel DMX unit.
2. Press the Up or Down buttons until “ADDR” is displayed, an press Enter.
4. Use the Up and Down buttons to find your desired address and press Enter. Connect your DMX Controller.
5. Use the controller’s faders to control the various DMX fixture traits.
6. For longer cable runs (more than a 100 feet) use a terminator on the last fixture.
7. For help operating in DMX mode consult the manual included with your DMX controller.
MASTER-SLAVE OPERATION (SOUND ACTIVE OR AUTO MODE): This function will allow you to link up to
16 units together and operate without a controller. The units be sound activate or run in a auto mode In can .
Master-Slave operation one unit will act as the controlling unit and the others will react to the controlling units
programs. Any unit can act as a Master or as a Slave.
1. This is a very simple process. Using standard XLR microphone cables, daisy chain your units together via
the XLR connector on the rear of the units. Remember the Male XLR connector is the input and the Fe-
male XLR connector is the output. For longer cable runs we suggest a terminator at the last fixture.
2. See Sound Active mode or Auto mode to select the “Master” option.
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
1 Year Limited Warranty: Eliminator Lighting warranty is valid from the date of purchase. Our
1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with
dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover
items or parts prone to wear and tear: motors, fuses, brushes and belts. Eliminator Lighting warranty
is only valid with-in the United States.
