Electro 86

SPECIFICATIONS:

Model: Electro 86

LEDs: 86 Pcs. (29 Red, 29 Green,

& 28 Blue)

Weight: 2.75lbs./ 1.258kgs.

Size: 6.5” (L) x 7.75” (W) x 6” (H)

Fuse: 1 Amp

Supply Voltage: 120V / 230V

Working Position: Any Safe position

Duty Cycle: None

DMX Channels: 4

Colors: Multiple Colors

Warranty: 1 Year

CAUTION! Please read and

understand these instructions

before installing or operating

this unit.

Operating Instructions:

The Electro 86 has been tested at the fac-

tory, there is no assembly required. The unit

is ready to be plugged into a power outlet.

This unit is a 4 channel DMX intelligent LED

pinspot. It can be run as a stand-alone, static

unit, DMX controlled unit, or in a Master/

Slave configuration. While in Stand Alone or a

Master/Slave configuration, you may choose

between sound active mode, auto run chase,

or static color. For stand-alone mode, Master/

Slave mode, and Master/Slave configuration

settings, see other side.

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

Caution! Never open unit when in use.

Always disconnect main power before

replacing fuse. Remember to always

replace with the exact same type fuse.

DMX TRAITS:

CHANNEL 1: RED

CHANNEL 2: GREEN

CHANNEL 3: BLUE

CHANNEL 4: INTENSITY & STROBE SPEED

0 - 189 = INTENSITY

0% - 100%

190 - 250 STROBE

SLOW - FAST

251 - 255 NO FUNCTION
