Flash 192

SPECIFICATIONS:

Model: Flash 192

Voltage: 100V-230V 50/60Hz

LEDs: 192 x 0.06W

Beam Angle: 60 Degrees

Power Consumption: 15W

Weight: 3.59lbs./ 1.63kgs.

Size: 11”(L) x 7.87”(W) x

2.36”(H) (w/o Bracket)

11”(L) x 7.87”(W) x

7.87”(H) (w/ Bracket)

Fuse: 1 Amp

Power Cord Daisy Chain: 25 Fixtures Max.

Working Position: Any Safe position

Duty Cycle: None

DMX Channels: 4 DMX Channels

Colors: White

Warranty: 1 Year

CAUTION! Please read and under-

stand these instructions before

installing or operating this unit.

Operating Instructions:

The Flash 192 has been tested at the factory, there is no assembly required. The unit is ready to be

plugged into a power outlet. This unit is a 4 channel DMX intelligent strobe. It has 3 operating mode;

Manual mode, Sound Active, or DMX mode. The Flash 192 can be used as a stand alone unit or in a

master-slave conguration.

Fuse Replacement:Disconnect the unit from its power source. Remove the power cord from the

unit. Once the cord has been removed, you will nd that the fuse holder is located inside the power

socket. Insert a flat-head screw driver into the power socket and gently pry out the fuse holder.

Remove the bad fuse and replace with a new one. The fuse holder also has a holder for a spare fuse.

Power Cord Daisy Chaining: With this feature you can connect the xtures to one another using the

IEC input and output sockets. The quantity that can be connected is 25 xtures maximum. After 25

xtures you will need to use a new power outlet. They must be the same xtures. DO NOT mix xtures.

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

Caution! Never open unit when in use. Always

disconnect main power before replacing fuse.

Remember to always replace with the exact same

type fuse.
