Pagina 1/16
1
OCEANS 11
Multifunction Digital Reverb
Congratulations on your purchase of the Electro-Harmonix OCEANS 11
Reverb, the compact digital reverb pedal that does it all. Splash your tone
with subtle ambience using classic Hall and Plate, or drench your guitar in
surreal soundscapes with Shimmer and Modulation. A newly developed
Spring algorithm faithfully emulates the iconic drip of vintage Fender ®
reverb units. Unique and powerful polyphonic, dynamic, and auto-
triggering reverbs inspire radical experimentation. Instantaneous control
of infinite reverb unleashes a torrent of sonic possibilities for a truly
unparalleled reverb experience.
- TABLE OF CONTENTS -
Getting started with OCEANS 11 2
Connections 2
Controls 2
Descriptions of Reverb Types 4
Mode Button Functionality 5
Footswitch Functionality 7
Summary Chart 8
Secondary Knob Functionality 10
Infinite Reverb Functionality 14
Warranty Information and FCC Compliance 16
2
- GETTING STARTED WITH OCEANS 11 -
1. Plug the supplied EHX9.6DC AC Adapter into the jack at the top of the
OCEANS 11.
2. Plug your guitar into the INPUT jack and plug the OUTPUT jack into
your amplifier.
3. Turn the 11-position Reverb Type knob to the HALL setting for a
classic warm reverb.
4. Set the decay time using the TIME knob, the reverb tone with the
TONE knob, and the reverb volume with the FX LVL knob.
- CONNECTIONS -
INPUT Jack – This ¼” jack is the audio input of the OCEANS 11. The
input impedance is . 1M
OUTPUT Jack – This ¼” jack is the audio output of the OCEANS 11. The
output impedance is 680 .
INFINITE Jack – Connect an external momentary footswitch to this ¼”
jack. Press and hold the external switch to activate infinite reverb. The
infinite reverb wash will continue as long as the external switch is pressed.
The external switch should be normally open. Upon engaging the switch,
it should create a short circuit between the Tip and Sleeve of the plug.
See “Infinite Reverb ” on page Functionality 14 for details on using infinite
reverb.
9V Power Jack – Plug the output of the OCEANS 11’s supplied EHX9.6DC
200mA AC adapter in the 9V power jack located at the top of the pedal.
The OCEANS 11 requires 150mA at 9VDC with a center-negative plug.
- CONTROL -S
FX LVL Knob Controls the output volume of the reverb effect. When –
this knob is at the minimum position, the output is only your dry signal.
As the knob is turned up, the reverb output increases in volume. As the
knob is turned past 2 o’clock, the dry signal decreases in volume. When
the knob is at the maximum position, only the effect is output.
TIME Knob Usually controls the decay time of the OCEANS 11 reverb. –
As this knob is turned clockwise, the reverb time gets longer and longer,
reaching infinite when the knob is as far as it will go.
3
TONE Knob – Usually controls the tone or EQ of the reverb signal. As this
knob is turned clockwise, the sound of the reverb gets brighter. As you
turn TONE counter-clockwise, the sound of the reverb gets darker.
Reverb Type Knob This knob is an 11-position rotary switch that –
selects which of the OCEANS 11's reverb types is active. See “Descriptions
of Reverb Types” on page 4 for details on the reverb types.
MODE Button – This button cycles through the available modes of the
active reverb type. Each reverb type has a certain number of modes which
modify the behavior of the active reverb type. See Mode Button “
Functionality on page for more details. 5
LED – The LED lights when the OCEANS 11 effect is active and shuts off
when in bypass mode. Its color and blinking pattern also indicate
information about the reverb mode, tap tempo delay, and infinite status.
See “Mode Button Functionality” on page 6, “Footswitch Functionality” on
page 8, and “Infinite Reverb Functionality” on page 14 for more details.
Footswitch Press the footswitch to toggle the pedal between buffered –
bypass and effect modes. When the pedal is in effect mode, the LED will
be lit. In most reverbs, the footswitch can also engage Infinite by pressing
and holding it down. Moreover, the footswitch can be used for tap tempo
in ECHO reverb. For more details se Footswitch Functionalitye “ ” on page
7 and “Infinite Reverb Functionality” on page 14.
TAILS Switch The OCEANS 11 allows you to choose whether reverb –
continues to play or stop immediately after the pedal is switched to
bypass. To control this, remove the OCEANS 11's bottom cover and locate
the small slide switch on the bottom of the board labeled “TAILS.” When
TAILS is set to ON, the reverb will continue to play after the pedal switched
to bypass, with the decay time set by the TIME knob. Anything you play
after entering bypass will not reverberate. If the pedal is set for infinite
decay time (i.e. TIME is set to maximum) the reverb will continue until
you turn TIME down or switch to a different mode.
