Q-TRON

Envelope Controlled Filter

-OPERATING INSTRUCTIONS-

Congratulations on your purchase of the

Q-Tron

envelope controlled lter! You have

purchased a very powerful tool for musical expression.

Please take a few minutes to familiarize yourself with the

Q-Tron’s

controls and how they

work.

Envelope controlled filters are a unique type of sound modier where the intensity of the

eect is controlled by the user’s playing dynamics.

The volume (also know as the envelope) of an incoming audio signal is used to control a

swept lter. As the volume increases or decreases so does the pitch of the lter.

-CONTROLS-

Drive Switch

(Up/Down) – Selects direction of filter sweep

Range Switch

(HI/Lo) – Emphasizes vowel-like sound in low position and overtones in high

position.

Gain Control

(0-11) – Functions as both a volume control and a lter sensitivity control in

boost mode. In Normal mode the Gain control acts as a lter sensitivity control and has no

eect on the unit’s output volume.

Boost Switch

(Normal/Boost) – Normal mode disengages internal pre-amp, Boost mode

activates it. Also determines function of Gain control (see above).

Peak Control

(0-11) – Determines frequency peak of lter. This control will create a more

dramatic eect when turned clockwise.

Mode Switch

(LP, BP, HP, MIX) – Determines what frequency range the filter will sweep in.

Emphasizes lows in Low Pass, midrange in Band Pass, treble in High Pass. Mix mode

combines BP with dry instrument signal.

Bypass Switch

(in/out) – Disengages eect.

Lastly, the

Q-Tron’s

eect can be controlled by the user’s playing dynamics. A strong attack

will yield a more dramatic eect, while softer playing will yield more subtle eects or none at

all.
