Semi-Solid State

Power Bank

UserManual

Howtousethepowerbank

English

DE-A07-10000 series

Thankyouforpurchasingthisproduct.

Pleasereadthisusermanualbeforeuseandkeepitforfuturereference.

FivetipsforsafeuseStopusinginthefollowingcases

Donotcover

withbedding

orcloth

Donotuse,leave,or

storeinhigh-temperature

environments

Donotapply

strongimpactor

pressure

Chargewithin

sight

Donot

exposeto

water

Swollenor

leaking

Wet

Damagedordeformed

powerbank

Damageinsidetheport,

suchasbentorbrokenpins

*Whenchargingbegins,thebatterylevelindicatorlightsupandthemarkﬂashes.

*Besuretodisconnectthecableafterchargingiscompleted.

Leavingitconnectedmayleadtodamageoftheconnectorpart.

*Whenthebatterylevelindicatorreaches100%or

turnsoﬀ,thebatteryisfullycharged.

*NoACchargerisincluded.

*AnACchargerof35Worhigherisrecommended.

IfanACchargeroflowerthan35Wor

aUSBType-CUSB-Acableisusedforcharging,

thebatterymaynotbefullychargedwithinthetime

indicatedonthepackageorwebsite.

ConnectachargingcabletotheUSBType-Cport1or2oftheproduct.

ConnecttheotherendofthechargingcabletoanACcharger(soldseparately).

ChargingbeginswhenyouconnecttheACchargertoahouseholdoutlet.

Afterchargingiscompleted,disconnectthechargingcableinorderof③,②,and①inthe

ﬁgureforyoursafety.

①

②

③

④

Howtochargetheproduct

USBType-Cconnector

②

③

①

Powerbutton

Batterylevelindicator

BatterylevelindicatorBatterylevelindicator

·USBType-Cconnector

·USB-Aconnector

ACcharger

(soldseparately);

35Worhigheris

recommended

*Whenchargingtheconnecteddevicebegins,thebatterylevelindicatorlightsupandthemarkturnsgreen.

*Ifchargingdoesnotbegin,quicklypressthepowerbutton(forapproximatelyonesecondorless).

*Theproductmaynotchargeuptothecapacity/numberoftimesindicatedonthepackageorwebsiteiftheconnected

devicesuchasasmartphoneortabletispoweredonorinuseduringcharging.

*Leavingthecableconnectedwillconsumethebattery.Besuretodisconnectthecablewhenitisnotused.

*Atlowambienttemperatures,thedischargetimemaybereducedorthemaximumoutput(W)maydecrease.

Howtochargeasmartphoneortablet

ConnectachargingcabletotheUSBType-C

port1/2orUSB-Aport1oftheproduct.

Connecttheotherendofthechargingcabletoadevicesuchasasmartphonetostartcharging.

Afterchargingiscompleted,disconnectthechargingcableinorderof②and①inthe

ﬁgureforyoursafety.

①

②

③

Powerbutton

USBType-Cport1

USBType-Cport1USBType-Cport1

②

·USBType-Cconnector

·USB-Aconnector

·USBType-Cconnector

·Lightningconnector

·USBMicro-Bconnector

①

USB-Aport1

USB-Aport1USB-Aport1

USBType-Cport2

USBType-Cport2USBType-Cport2

DonotconnectabatteryordevicethathasaUSB

Type-Cinput/outputporttotheproductwitha

chargingcable.Doingsomayfailtochargeyour

intendeddevice.

Connectingtoabatteryordevice

withUSBType-Cinputandoutput

Portsandoutputs(W)

C2A1C1

*C1:USBType-Cport1

*C2:USBType-Cport2

*A1:USB-Aport1

20Wmax(total)

C1+C2/C1+A1/C2+A1

20Wmax(total)

C1+C2+A1

35Wmax

(PPS:33Wmax)

C1/C2

22.5W

max

Howtocheckthebatterylevelanduselow-currentmode

Tocheckthebatterylevel

*Toturnoﬀthebatterylevelindicator

①

Theindicatorwillautomaticallyturnoﬀafterapproximately30seconds.

②Quicklypressthepowerbuttontoturnitoﬀmanually.

*Approximately2000rechargeablecycles(JISC8711)

Quicklypressthepowerbutton.Thebatterylevelindicatorshows

theremainingchargein1%incrementsaccordingtothebatterylevel.

Ifanabnormalityisdetectedduringuse,theprotectionfunction

willbeactivated.Then,188willﬂashorinput/outputwill

stop.Tocanceltheprotectionfunction,followthestepsbelow.

①



Disconnectallchargers,devices,andcablesconnectedtotheproduct.

②



Checkthatthebatterylevelindicatorturnsoﬀ.

*Iftheprotectionfunctionisrepeatedlyactivated,stopusingtheproduct.

Whentheprotectionfunctionisactivated

Low-currentmode

ConnectsmallelectronicdevicessuchasBluetooth



earphonesorheadsetstotheUSB-Aport1foruse.

OFF

Pressthepowerbuttontwiceinsuccession.Thelow-currentmodeiscanceled.

Pressthepowerbuttontwiceinsuccession.The

●

indicatorturnsgreen.

Thelow-currentmodeisautomaticallycanceledapproximatelytwohoursafterbeingactivated.

Thelow-currentmodemaynotbeautomaticallycanceledinthefollowingcases.

·Theconnecteddeviceisfullycharged.

·Nodeviceisconnected.

*Evenwhiledischarginginlow-currentmode,themarkmaynotlightif

thedischargecurrentislow.

Howtochargetheproductandasmartphoneatthesametime

①ConnectoneendofachargingcabletotheUSBType-Cport1/2orUSB-Aport1

oftheproduct.

②Connecttheotherendofthechargingcabletoadevicesuchasasmartphone.

③ConnectoneendofanotherchargingcabletotheopenUSBType-Cport1or

2andtheotherendtoanACcharger.

④ChargingbeginswhenyouconnecttheACchargertoahouseholdoutlet.

Theinput/outputspeciﬁcationsforchargingallatonceareasfollows:

Input15Wmax(5V/3A)/Output15Wmax(5V/3A)

*Theproductusespass-throughcharging.

Devicessuchasasmartphonearechargeddirectlyfromthechargerbybypassingthebattery.

*Whenchargingbegins,thebatterylevelindicatorlightsupandthemarkﬂashes.

*Ifchargingdoesnotbeginfortheconnecteddevicesuchasasmartphone,quicklypressthepower

button(forapproximatelyonesecondorless).

*Chargingmaynotbepossiblewithsomedevices.

*1AfterconnectingoneendofachargingcabletotheUSB-Aport1,connecttheotherendtoa

devicesuchasasmartphoneinsteadofanACcharger.

③

①

④

②

Powerbutton

Batterylevel

indicator

On:Discharging

Flashing:Charging

On:Low-currentmode

HealthMonitor

LEDcolormeanings

*Regardlessoftheindicatorstatus,ifyounoticeanysignssuchasswelling,unusualodor,

orabnormalheat,stopusingtheproductimmediately.

·

Oﬀ:Uptoapproximately250cyclesThebatteryisinastable

condition.

·

Blue:Approximately251‒500cyclesBatteryperformancemaybe

startingtograduallydecline.Payattentiontooverheatingand

batterylife.

·

Orange:Approximately501cyclesormoreBatteryperformancemay

havedeteriorated.Forsafeandcomfortableuse,considerreplacing

theproduct.

Thisfunctionprovidesageneralindicationofthebatterycondition

basedonthenumberofcharge/dischargecycles.
