2.2 LOCATION AND LAYOUT
1
Contents
Introduction 1
Installation 1
Use, safety 2
Cleaning, hygiene and storage 4
Fault nding 5
Maintenance 6
Conformity with regulations 7
GB
12/2023
This document is to be used in conjunction with the original manufacturer’s manual.
The symbols correspond with the numbered drawings of the original manual.
TRS GB 09 06
2.2
Introduction
1.1 DESCRIPTION
The multi-purpose vegetable cutting machine can slice, shred,
grate, chip and dice various foodstus (for the preparation of raw
and cooked vegetables, fruits and cheeses).
With its range of high output cutters, the machine is the profes-
sional vegetable cutter for restaurants, large kitchens and small
companies.
A Body
B Stop button (red)
C Start button (black)
D Feed stick
E Feed arm
F Large feed hopper
G Cover
H Discharge chute
I Cover lock
J Feet
K Plastic of stainless steel housing, depending
on models
1.1
Installation
2.1 DIMENSIONS - WEIGHT (for information only)
• Dimensions of packaging in mm :
L : 630 W : 270 h : 530
• Dimensions of the machine :
Gross weight when packaged : 20kg
Net weight when equipped : 18kg (excluding cutters)
2.1
• For larger bowls, position the TRS on the edge of the table or
use the mobile work base.
- Remove the feed pusher from the chute (anti-clockwise
Introduction
The User Manual contains useful information for the user on how
to work correctly and in complete safety, and is designed to make
it easier to use the machine (called «machine» or «appliance»
below).
What follows is in no case intended to be a long list of warnings and
constraints, but rather a series of instructions meant to improve the
service provided by the machine in every respect, and particularly
to avoid a series of injuries or damage to equipment that might
result from inappropriate procedures for use and management.
It is essential that all the people responsible for transporting,
installing, commissioning, using, maintaining, repairing or dis-
mantling the machine should consult this manual and read it
carefully before proceeding with the various operations, in order
to avoid any incorrect or inappropriate handling that might be
result in damage to the machine or put people’s safety at risk.
It is just as important that the Manual should always be available
to the operator and it should be kept carefully where the machine
is used ready for easy and immediate consultation in case of any
doubt, or in any case, whenever the need arises.
If after reading the Manual, there are still any doubts concerning
how to use the machine, please do not hesitate to contact the
Manufacturer or approved After Sales Service provider, who is
constantly available to ensure quick and careful service for im-
proved machine operation and optimum eciency.
Note that the safety, hygiene and environmental protection stan-
dards currently applicable in the country where the machine is
installed must always be applied during all phases of machine
operation. Consequently it is the user’s responsibility to ensure
that the machine is operated and used solely under the optimum
safety conditions laid down for people, animals and property.
The machine may be :
• Fitted on a table of between 700 and 900 mm maximum in height
and take a standard 150 mm high receiving bowl.
• Fitted on a mobile work base (available in option).
! Always place the machine on a strong, at, stable
support
The reference language for these instructions is French.
• Motor characteristics :
B Number of phases (1 single phase or 3 triple phase)
C Nominal voltage in volts (value, range or commutation)
D Frequency (Hertz)
E Nominal power (Watt)
1) Three phase dual voltage motor.
• Provide an accessible wall-mounted power outlet standardized
with 3 poles + Ground, rated 20 A compliant with IEC60309, and
a corresponding waterproof plug to be mounted on the power
cord. This installation and any replacement of the plug must be
carried out according to good professional practice by a qualied
and authorised electrician. Do not use a xed connection between
the machine and power supply
2.3
• Check the direction of rotation using the ejector tted to the
machine.
- Remove the feed pusher from the chute (anti-clockwise
direction
) .
- Press the start button.
- Check the direction in which the ejector is turning by means of
the chute. The ejector should be turning anticlockwise .
• If it is turning in the opposite direction, change over the two
phase wires in the plug.
• The connection is pre-set for high voltage (e.g.400 V).
For use with low voltage
(e.g. 230 V),proceed as follows :
! Earthing is mandatory, using a green/yellow
conductor.
6.4
2.3 ELECTRICAL CONNECTION
Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised
person (see current standards and legislation in the country of installation).
If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than
those of the machine.
Do not use multiple plugs
The AC power supply to the machine must comply with the following conditions EN602040-1;
- Maximum voltage variation: ±10%
- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods
ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard
requirements in the country where used.
- Before connecting the machine to the electrical power supply, check that the voltage of the electrical system is the same as that
marked on the rating plate.
- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using
a circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and
machine specications - see the specications shown in column G of gure 2.3a
ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and
connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1
(IEC 60204-1) with the use of protection devices for automatic shut-o of power in the event of an insulation fault with
a TN or TT system, or, for the IT system, with the use of a permanent insulation or dierentials controller for automatic
shut-o. The requirements of IEC 60364-4-41, 413.1 must apply for this protection.
For example: in a TT system, a dierential circuit breaker must be installed upline of the power supply, with a suitable
power cut-o (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.
ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-
dents due to direct or indirect contacts.
ATTENTION !!
2
TRS GB 12 2023
To PAT test the Electrolux Range of Food Preparation Equipment,
the PCB board needs to be disconnected before any test is done.
This is due to the fact that the boards are tted with a grounding
diode that can give incorrect result during such a test. Also on a
standard appliance a ash test of 25 amps and up to 3000v is
used but, as you would expect, to use this on equipment, which
has a printed circuit, board would be quite destructive to that
board. We would recommend the use of a PAT tester approved
for computer systems which use a lower rate of amps.
The appliance is perfectly safe and is CE certicated. There are
two ways to get overcome this problem.
• Disconnect the board as instructed and test using test for PC’s,
• Or install the mixer on a fused spur (no plug) as this takes it
away from being a portable appliance and the PAT test is then
not needed.
- Disconnect the machine and turn it over.
- Remove the 4 screws xing the casing.
- Change the wire on the integrated circuit board by moving the
cable spade from the terminal connection marked at the higher
voltage (400V) onto that marked at the lower voltage (230V).
- Change the connection of the motor wiring.
- Check the direction of rotation and ret the casing.
2) Single phase motor.
Provide an accessible standardized wall outlet with 2 poles +
ground, rated at 10/16A in accordance with IEC60309, and a
corresponding waterproof plug to be installed on the power cord.
Clean the machine properly prior to its rst use
This machine is for professional use and must be used by sta trained to use, clean and maintain it, in terms or reliability and safety.
Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard
EN 12464-1)
When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the
lower limbs.
Uncontrolled closure of the lid or ram press involves a risk of crushing the ngers.
Never put a hand in the ejection area while the machine is in operation; risk of injury. It is strictly forbidden to put the safety systems
out of action or modify them: Risk of permanent injury!!!!
Check that the safety devices operate correctly each time before using (see paragraph on «safety system adjustments»).
Never put a hand, a hard or frozen object in the appliance
For health and safety reasons, always use a washable or disposable strong head covering that covers the hair completely.
ATTENTION: All operations, whether using, cleaning or maintenance, present risks of cuts; never force and always keep
hands a reasonable distance from cutting edges.
Always use appropriate protective equipment when carrying out these operations.
The machine is not designed for use in explosive atmospheres.
ATTENTION !!
Use, safety
3.1 USER SAFETY is ensured by :
- The braked stoppage of the motor when the feed arm is opened
so that there is no risk when loading.
- The motor not starting if the cover is missing.
- The size of the small feed hopper for long vegetables.
- If the machine does not stop within less than 2 seconds or does
not stop at all when the upper cover is opened, unplug it and
contact your technical assistance service immediately.
- The absence of risk of access via the discharge chute due to
the design of the ejector and the discs.
- Respecting the instructions of this manual for the use, cleaning
and maintenance of the machine.
RESIDUAL RISKS
The machine presents the following residual risks;
• The upper cover of the machine may result in the ngers being
crushed if it is closed without being controlled properly.
• If a hand is placed in the area where the products are discharged,
it may be crushed or trapped by the rotating parts of the machine.
3.2 CHOICE OF THE CUTTERS
• C slicing discs : for straight cuts from 1 to 13 mm.
• crinkle cut from 2 to 10 mm for:CW slicing discs :
- Vegetables: potatoes, carrots, aubergines, beetroot, celery,
cabbages, mushrooms, cucumbers, courgettes, chicory, fennel,
onions, leeks, radishes, etc.
- Fruits : almonds, bananas, apples, etc.
• for cutting into chips of 2 to 5 mm.AS shredding discs :
- AS 2X : thin 2 x 2 mm
- AS 3X : medium 3 x 3 mm
- AS 4X : large 4 x 4 mm for matchstick potatoes
- :AS 6X
- :AS 8X
- :AS 10X
• J - P - K grating discs
• medium large J 2 J 3 ne J 4 J 7 extra large
3.2a
- Vegetables : carrots, «doorstep» potatoes, grated celery, red
cabbages, beetroots, horseradishes, rösti.
- Cheeses : gruyère, mozzarella.
- Other : almonds, breadcrumbs, chocolate, etc.
• P : for Parmesan, breadcrumbs, almonds, horseradishes,
chocolate.
• K : special grating of raw potatoes (Knödeln).
FT chip grids : for cuts from 6 to 10 mm in thickness when used
with a C/CW disc of the same thickness.
• MT Dicing grids : for square section cuts of 5 to 20 mm when
used with a C/CW disc for :
- Cubes or diamonds: macedoines of vegetables or fruits, jardi-
nières, minestrones, sauted or braised potatoes, stews.
Indicative outputs until 550 kg / h :
Potatoes C 5 360
Chips C 8 + FS 8 450
3.2c
3.2d
3.2e
3.2f
straw potatoes,
celery, carrots
}
3
TRS GB 10 2015
Product specificaties
| Merk: | Dito Sama |
| Categorie: | Snijmachine |
| Model: | 602206 |
Heb je hulp nodig?
Als je hulp nodig hebt met Dito Sama 602206 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Snijmachine Dito Sama
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
Handleiding Snijmachine
- Krups
- Korona
- Hyundai
- Turmix
- Arendo
- Makeblock
- Esperanza
- Boska
- Hobart
- Wilfa
- Garde XL
- Choice
- Weston
- Prowork
- Severin
Nieuwste handleidingen voor Snijmachine
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
11 Augustus 2025
