This document is to be used in conjunction with the original manufacturers manual.
The symbols correspond with the numbered drawings of the original manual
Contents
GB
05/2024
Fault nding 4
Maintenance 5
Conformity with regulations 6
Introduction 1
Installation 1
Use, safety 2
Cleaning, hygiene and storage 4
Introduction
1.1 DESCRIPTION
The automatic French fries cutter is a machine for profesisonal
use that allows obtaining fresh fries of excellent quality and to cut
potatoes in slices.
A Cutter block
B Mobile stainless steel stand (option)
C Polished aluminium body
D Stainless steel feed hopper
E Hopper locking lever
F START button
G STOP button
H Outlet chute
• Thanks to its high output and adapted cutting equipment, the
machine satises the requirements of restaurants, catering
kitchens and food industries.
Installation
2.1 DIMENSIONS - WEIGHT (For information only)
Dimensions of packaging:
- machine L x W x H (mm): 755 x 410 x 680
- stand L x W x H (mm): 750 x 500 x 200
Dimensions of the machine:
- without stand: L x W x H (mm): 670 x 360 x 556
- with stand: L x W x H (mm): 736 x 458 x 1264
Weight :
- gross when packaged: 45 kg
- net equipped (with rotor and without cutting equipment): 37 kg
- net of stand: 15 kg
2.2 LOCATION AND LAYOUT
The machine (whether packed or not) is meant to be lifted
using a forklift truck. If manual handling is going to be used for
the machine on its own, two people are needed (for all machines
weighing more than 25 Kg)
On a table of between 600 and 750 mm maximum in height.
On a stand (available as an option) which can hold large capacity
collection tubs.
To block and level the stand:
- Unscrew the lock screw on the two adjustable feet (10 mm
socket spanner).
- Adjust the foot then lock in position.
- Check that the machine is stable.
If necessary, anchor the stand in position:
- Counter drill the attachment holes of the feet (5 mm dia.
screws x 40 mm long and rawl plugs not supplied).
Introduction
The User Manual contains useful information for the user on how
to work correctly and in complete safety, and is designed to make
it easier to use the machine (called «machine» or «appliance»
below).
What follows is in no case intended to be a long list of warnings and
constraints, but rather a series of instructions meant to improve the
service provided by the machine in every respect, and particularly
to avoid a series of injuries or damage to equipment that might
result from inappropriate procedures for use and management.
It is essential that all the people responsible for transporting,
installing, commissioning, using, maintaining, repairing or dis-
mantling the machine should consult this manual and read it
carefully before proceeding with the various operations, in order
to avoid any incorrect or inappropriate handling that might be
result in damage to the machine or put people’s safety at risk.
It is just as important that the Manual should always be available
to the operator and it should be kept carefully where the machine
is used ready for easy and immediate consultation in case of any
doubt, or in any case, whenever the need arises.
If after reading the Manual, there are still any doubts concerning
how to use the machine, please do not hesitate to contact the
Manufacturer or approved After Sales Service provider, who is
constantly available to ensure quick and careful service for im-
proved machine operation and optimum e󰀩ciency.
Note that the safety, hygiene and environmental protection stan-
dards currently applicable in the country where the machine is
installed must always be applied during all phases of machine
operation. Consequently it is the user’s responsibility to ensure
that the machine is operated and used solely under the optimum
safety conditions laid down for people, animals and property.
1 RC14 GB 02 2016
The reference language for these instructions is French.
Motor characteristics:
B Number of phases (1 single phase - 3 three phase)
C Nominal voltage in Volts (value, range or commutation)
D Frequency (Hertz)
E Nominal power (Watts)
F Nominal current (Amperes)
G Rating of fuse protecting electrical supply (Amperes)
H Approximate electrical consumption (Kwh)
I Thermal relay setting (Amperes)
1) Dual voltage three phase motor
•Provide an accessible wall-mounted power outlet standardized
with 3 poles + Ground, rated 20 A compliant with IEC60309, and a
corresponding waterproof plug to be mounted on the power cord.
Check the direction of rotation of the rotor tted to the machine.
- Press the START button
- Release the hopper locking lever and lift the hopper.(see §3.3)
- The rotor must turn in an anti-clockwise direction .
If the direction of rotation is incorrect, change over any two
phase wires at the plug/isolator.
The connection is pre-set for high voltage (e.g. 400 V).
For use with low voltage (e.g. 230 V), proceed as follows:
- Unplug the machine and turn it upside down.
- Unscrew the four feet to remove the base and gain access to
the electrical components.
- Change the wire on the integrated power board by moving the
cable spade from the terminal connection marked at the higher
voltage (400V) onto that marked at the lower voltage (230V).
- Modify the position of the connector strips of the motor connec-
tion housing.
Note: Do not change the current setting on the thermal
relay.
2) Single phase motor
Provide an accessible standardized wall outlet with 2 poles
+ ground, rated at 10/16A in accordance with IEC60309, and a
corresponding waterproof plug to be installed on the power cord.
The machine must be earthed with a green / yellow wire.
2.3a
2.3 ELECTRICAL CONNECTION
Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised
person (see current standards and legislation in the country of installation).
If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than
those of the machine.
Do not use multiple plugs
The AC power supply to the machine must comply with the following conditions EN60204-1;
- Maximum voltage variation: ±10%
- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods
ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard
requirements in the country where used.
- Before connecting the machine to the electrical power supply, check that the voltage of the electrical system is the same as that
marked on the rating plate.
- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using
a circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and
machine specications - see the specications shown in column G of gure 2.3a
ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and
connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1
(IEC 60204-1) with the use of protection devices for automatic shut-o󰀨 of power in the event of an insulation fault with
a TN or TT system, or, for the IT system, with the use of a permanent insulation or di󰀨erentials controller for automatic
shut-o󰀨. The requirements of IEC 60364-4-41, 413.1 must apply for this protection.
For example: in a TN or TT system, a di󰀨erential circuit breaker must be installed upline of the power supply, with a
suitable power cut-o󰀨 (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.
ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-
dents due to direct or indirect contacts.
ATTENTION !!
To PAT test the Electrolux Range of Food Preparation Equipment,
the PCB board needs to be disconnected before any test is done.
This is due to the fact that the boards are tted with a grounding
diode that can give incorrect result during such a test. Also on a
standard appliance a ash test of 25 amps and up to 3000v is
used but, as you would expect, to use this on equipment, which
has a printed circuit, board would be quite destructive to that
board. We would recommend the use of a PAT tester approved
for computer systems which use a lower rate of amps.
The appliance is perfectly safe and is CE certicated. There are
two ways to get overcome this problem.
· Disconnect the board as instructed and test using test for PC’s,
· Or install the mixer on a fused spur (no plug) as this takes it
away from being a portable appliance and the PAT test is then
not needed.
2.3b
RC14 GB 04 2024 2
Use, safety
3.1 THE SAFETY OF THE USER IS ENSURED BY:
- Check that the safety features operate correctly prior to each use.
The safety features take priority over the operating sequence.
- Stoppage of the motor when the lid is opened. 0<stop<30mm
- The machine not starting if the cutter block is not tted.
- The START button needing to be pressed after stoppage
("no volt" release).
- Rotor braking <4 seconds
- Method of isolation: disconnect the appliance plug from the
socket.
- The absence of any risk from the outlet chute due to the design
of the machine.
- Following the instructions in this manual for the use, cleaning
and maintenance of the machine.
3.2 CHOICE OF CUTTING EQUIPMENT
• The cutting equipment for slicing or chipping includes:
- a cutter block,
- a rotor which is common to all of the cutter blocks.
Available cutter blocks:
1) Chipping block: cross sections of 8 x 8 - 10 x 10 - 12 x 12 - 14
x 14 mm.
2) Scallop blocks: thicknesses of 4 - 6 - 8 mm.
Theoretical outputs:
12 mm chips: 1500 kg/hour with 40/80 grade potatoes.
3.2b
3.2a
3.3 USE OF THE EQUIPMENT
The potato chipper is supplied with the rotor tted and the cutter
blocks packed separately.
Note: Before using the machine, always check that
the cutting chamber, drive shaft, hopper and cutting
equipment are clean.
To t the cutting equipment to the machine:
1) Unscrew the knob in an anti-clockwise direction to release
the hopper.
2) Raise and remove the hopper.
3) Fit the rotor onto the bayonet connector of the shaft and check
that it is tted correctly. The rotor should be ush with the end
of the shaft.
4) Fit the cutter block. Check that the block is tted correctly.
5) Reinsert the hopper and lock it by turning the handle clo-
ckwise .
6) Press the black START button.
3.4 USE
The potato chipper will only operate if the hopper is locked
correctly.
• The rotor can cut potatoes up to grade 80 maximum.
Load the machine by pouring a bucket of potatoes into the hopper.
The vegetables are gravity fed to the rotor and centrifugal force
takes them to the blades of the cutter block, where they are cut.
3.3a-b
Clean the machine properly prior to its rst use
This machine is for professional use and must be used by sta󰀨 trained to use, clean and maintain it, in terms or reliability and safety.
Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard
EN 12464-1)
When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the
lower limbs.
If the hopper closes in uncontrolled fashion, there is a risk of crushing for the ngers.
Never put a hand in the ejection area while the machine is in operation; risk of injury. It is strictly forbidden to put the safety systems
out of action or modify them: Risk of permanent injury!!!!
Check that the safety devices operate correctly each time before using (see paragraph on «safety system adjustments»).
Never put a hand, a hard or frozen object in the appliance
For health and safety reasons, always use a washable or disposable strong head covering that covers the hair completely.
ATTENTION: All operations, whether using, cleaning or maintenance, present risks of cuts; never force and always keep
hands a reasonable distance from cutting edges.
Always use appropriate protective equipment when carrying out these operations.
The machine is not designed for use in explosive atmospheres.
ATTENTION !!
3 RC14 GB 05 2024
Any other use than that described in this manual will not be consi-
dered normal by the manufacturer.


Product specificaties

Merk: Dito Sama
Categorie: Snijmachine
Model: 603431

Heb je hulp nodig?

Als je hulp nodig hebt met Dito Sama 603431 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden




Handleiding Snijmachine Dito Sama

Handleiding Snijmachine

Nieuwste handleidingen voor Snijmachine
