LED Indoor Luminaires Model # ALNV280520LAJD2 xx

Vanity Wall Mount ALNV400530LAJD2 xx

120277-VAC / 60Hz ALNV540540LAJD2xx

Page 1 of 18061288 R0

Limited Factory Warranty

AFX Inc. hereby warranty that this xture is free from defects in materials and workmanship when installed and used under normal operating conditions for a period of 5 years

from date of shipment from factory. This warranty covers all component parts and extends only to replacement of defective xture or components; it does not cover failure due

to improper installation, misuse, mishandling or damage incurred in transit.

Safety Precautions

Read all safety precautions and installation instructions carefully before installing or servicing this xture. Failure to comply with these instructions could result in potentially fatal

electric shock and/or property damage.

It is recommended that a qualied electrician perform all wiring. This xture must be wired in accordance with all national and local electrical codes.

Do not handle any energized xture or attempt to energize any xture with wet hands or while standing on a wet or damp surface or in water.

This xture is designed for use in a 120-277This xture is compatible with 0-dimmers. VAC, 60Hz fused circuit. 10V

Make sure that the power source conforms to the requirements of the xture. (See labels on the xture housing).

To reduce the risk of electrical shock, and to assure proper operation, this xture must be adequately grounded. To accomplish proper grounding, there must be a separate ground

wire (green) contact between this xture and the ground connection of your main power supply panel.

This xture is intended to be used for general indoor lighting in dry or damp locations.

Disclaimer

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been

tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and Canadian ICES--005 (B). These limits are designed to 005 (B) / NMB

provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiver antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult with the dealer or an experienced radio/TV technician for help.

Any modications to this xture may void the warranty and interfere with the safe operation of the luminai re.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may

cause undesired operation of the device.

Assembly Instructions

1.Preparing for installation.

A. Disconnect electrical powerbefore installing or servicing any part of this

xture.

B. Remove fixture from carton; remove components from hardware kit.

C. Place the diuser assembly (9), channel cover (7) and hardware o to the

side.

D.Remove appropriate knockout( s) on channel assembly (1) for power supply

entry.

E. Install white cover plate (4) to junction box (not included) with two screws (5).

F. Position the channel assembly (1) onto the wall facing the proper direction

and mark all appropriate mounting locations. Take the channel assembly (1)

down and punch a small hole in the wall at each of the marked locations

using a nail to see if there is a wall stud to mount the xture to. Where there

is a wall stud, use a suitable screws (2, not included) to mount the xture.

Where there is no stud to screw into, a toggle bolt or drywall anchor (3, not

included) must be used to mount the channel assembly securely to the wall.

2.Wiring.

All wiring must take place inside junction box (not included).Caution: Make

sure power is off at fuse or circuit breaker box. Check power wires for damage or

scrapes. If the power supply wires are within three inches of the driver, use a wire

suitable for at least 90C (194F). Most dwellings built before 1985 have supply Note:

wire rated to 60C. Consult a qualied electrician before installing.

A. This unit will not operate properly unless connected to a “grounded” electrical

circuit. Electrical shock, overheating, low or no light output, and shortened LED life can result if proper grounding is not done. Securely

attached power source ground wire to xture green ground wire.

B. Make all wire connections to appropriate wire. Secure with wire nuts (provided)..

C.Connect black wire from the fixture to the black (L) wire from supply power source.

D.Connect white wire from the xture to the white (N) wire from supply power source.

E. . Pull on each wire lead to make sure connections are secure. Make certain no bare wires are exposed outside of Do not mix wires

wire connectors. Tuck all connections neatly into junction box.

3.Mounting channel cover.

A. Install channel cover assembly (7) to the channel (1) by rst connect mated pair connector (6) together then align front hole to the channel and secure with two screws (8).

4.Color Changing Temperature Adjustment, CCT (if desired).

B. Adjust the two switches on each board accordingly to the desired color temperature as seen below. All boards must be set the same way. Fixture is preset to 3500K from Note:

factory.

5.Mounting diuser.

A. Install the diuser (9) ligning two holes on top to channel (1) and secure with two nials ( by a10).

6.Power to the xture can now be restored .

3ft version shown for

reference only. Individual

models may vary.
