LED Indoor Ceiling Luminaires Model # ALDF1318LAJD1 xx

Ceiling Mount ALDF1525LAJD1 xx

120VAC / 60Hz ALDF2032LAJD1 xx

Page 1 of 1 8061169 R1

Safety Precautions

Read all safety precautions and installation instructions carefully before installing or servicing this xture. Failure to comply with these instructions could result in

potentially fatal electric shock and/or property damage.

It is recommended that a qualied electrician perform all wiring. This xture must be wired in accordance with all national and local electrical codes.

Do not handle any energized xture or attempt to energize any xture with wet hands or while standing on a wet or damp surface or in water.

This xture is designed for use in a 120VAC, 60Hz fused circuit.

To reduce the risk of electrical shock, and to assure proper operation, this xture must be adequately grounded. To accomplish proper grounding, there must be a

separate ground wire (green) contact between this xture and the ground connection of your main power supply panel.

This xture is intended to be used for general door lighting in dry or damp locations.in

Disclaimer

Changes or modications not expressly approved by the party responsible for compliance could void NOTE: This the user’s authority to operate the equipment.

equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and Canadian ICES-005 (B) / NMB-005

(B). These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiver antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult with the dealer or an experienced radio/TV technician for help.

Any modications to this xture may void the warranty and interfere with the safe operation of the luminaire.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference

t may cause undesired operation of the devichate.

Assembly Instructions

Step 1 Preparing for installation–

A. before installing or servicing any part of this xture Disconnect electrical power

B. Remove xture from carton; remove ceiling pan (4) with shade ) already attached, and (6

hardware kit. Remove the acrylic diuser (7) and set aside.

C. Install two shorter screws (2) to gem bar (1) embossed holes with screws facing the

xture until screw head is ush with gem bar . perFigure 1

D. Attach gem bar (1) to the junction box (not provided) with two long screws (3 ).

WiringAll wiring must take place inside junction box (not included). –

Caution: Make sure power is o at fuse or circuit breaker box. Check power wires for

damage or scrapes. If power supply wires are within three inches of LED driver, use wire

suitable for at least 90°C (194°F). Most dwellings built before 1985 have supply Note:

wire rated to 60°C. Consult a qualied electrician to ensure correct branch circuit

conductor before installing.

Step 2 Wiring xture –

A. Make all wire connections to appropriate wire. Secure with wire nuts (provided).

B. Connect the green wire from the xture to the supply power source ground wire.

C. Connect the white wire from the xture to the white (N) wire For none-dimming xture.

from supply power source. Connect the black xture wire to the black (L) wire from supply

power source.

D. For TRIAC dimming. Connect the white wire from the xture to the white (N) wire from

dimming source per dimmer wiring instructions. Connect the black wire from the xture to

the black (L) wire from dimmer supply power source per dimmer wiring instructions.

E. Pull on each wire lead to make sure connections are secure. Make Do not mix wires.

certain no bare wires are exposed outside of wire connectors. Tuck all connections neatly

into the junction box.

Step 3 Back pan mounting –

A. Align back pan (4) to two screws (2) on round gem bar and secure with two thumb nuts

(5) as shown in . Figure 2

Step 4 Color ChangingTemperature adjustment, CCT (if desired) –

A. Set the two color selection switches in according to the desired color Figure 2,

temperature as shown below. Fixture is preset to 3500K from factory. Note:

Step 5 Mounting diuser–

A. Install the acrylic diuser (7) into the shade (6). With the matte nish side of (7) facing down, bend it slightly to angle it up inside the shade as shown in . Figure 3

B. The diuser should fall into place at the bottom of the shade.

Step 6 Restore power at fuse or circuit breaker box–

Limited Factory Warranty

AFX Inc. hereby warranty that this xture is free from defects in materials and workmanship when installed and used under normal operating conditions for a period of 5 years from

date of shipment from factory. This warranty covers all component parts and extends only to replacement of defective xture or components; it does not cover failure due to

improper installation, misuse, mishandling or damage incurred in transit.
