AAF Series LED Flushmount Fixture

Models: AAF121400L30D1xx, AAF162600L30D1xx

Page 1 of 1 8061003 R0

AAF162600L30

model shown

Safety Precautions

Read all safety precautions and installation instructions carefully

before installing or servicing this fixture. Failure to comply with

these instructions could result in potentially fatal electric shock

and/or property damage.

It is recommended that a qualied electrician perform all wiring. This

xture must be wired in accordance with all national and local

electrical codes.

Do not handle any energized xture or attempt to energize any

xture with wet hands or while standing on a wet or damp surface or

in water.

This xture is designed for use in a 110-120VAC, 60Hz fused circuit.

Make sure that the power source conforms to the requirements of the

xture (see labels on xture housing).

To reduce the risk of electrical shock, and to assure proper operation,

this xture must be adequately grounded. To accomplish proper

grounding, there must be a separate ground wire (green) or bare metal

contact (metal conduit) between this xture and the ground

connection of your main power supply panel. The green ground

screw location is clearly marked on the gem bar.

This xture is intended to be used for general indoor lighting in dry

or damp locations only.

Assembly Instructions

1.Preparing for installation

A.Disconnect electrical power before installing or servicing any part

of this xture.

B.Separate xture (1) from mounting bracket (2), place xture and

parts bag o to the side.

2.Wiring.All wiring must take place inside junction box.

Caution: Make sure power is o at fuse or circuit breaker box. Check power

wires for damage or scrapes. If power supply wires are within three inches of

driver use wire suitable for at least 90°C (194°F). Most dwellings built Note:

before 1985 have supply wire rated to 60°C. Consult a qualied electrician

before installing.

A.This unit will not operate properly unless connected to a “grounded”

electrical circuit. Electrical shock, overheating, low or no light

output, and shortened lamp life can result if proper grounding is not

done. Securely attach power source ground wire and xture copper

ground wire to green ground screw on mounting bracket.

B.Using wire nuts (provided), connect white (common) supply wire to

white xture lead. Connect black (hot) supply wire to black xture lead. . Pull on each Do not mix wires

wire lead to make sure connections are secure. Make certain no bare wires are exposed outside of wire

connectors.

3.Fixture mounting

A.Align mounting bracket (2) to junction box (not supplied) with at side facing ward ceiling and secure rmly with two #8-to

32 x 1” screws (3). Install two wood screws (6) through outer slots into drywall anchor (5) for additional support.

B.Install pan (1) carefully to mounting bracket by aligning two side holes to the bracket and secure rmly with two screws (4).

4.Restore power at fuse or circuit breaker box.

Limited Factory Warranty

AFX Inc. hereby warranty that this xture is free from defects in materials and workmanship when installed and used under normal operating

conditions for a period of 5 years from date of shipment from factory. This warranty covers all component parts and extends only to replacement of

defective xture or components; it does not cover failure due to improper installation, misuse, mishandling or damage incurred in transit.
