Pagina 1/32

User manual 2

Manual de instrucciones 16

Dishwasher

Lavavajillas

ZSF2430

Contents

ContentsContents

Safety information _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 2

Control panel _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 3

Washing programmes _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 4

Use of the appliance _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 5

Setting the water softener _ _ _ _ _ _ _ _ _ _ _ _ _ _ 5

Use of dishwasher salt _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 6

Use of rinse aid _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 6

Loading cutlery and dishes _ _ _ _ _ _ _ _ _ _ _ _ _ 7

Use of detergent _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 8

Setting and starting a washing programme _ _ _ _ _ _ 9

Care and cleaning _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 10

What to do if… _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 11

Technical data _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 13

Environment concerns _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 13

Installation _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 13

Water connection _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 14

Electrical connection _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 15

Subject to change without notice

Safety

Safety Safety information

information

informationinformation

For your safety and correct operation of the appli-

ance, read this manual carefully before installation

and use. Always keep these instructions with the appli-

ance even if you move or sell it. Users must fully know the

operation and safety features of the appliance.

Correct use

Correct useCorrect use

• The appliance is designed exclusively for domestic

use.

• Only use the appliance to clean household utensils that

are applicable for dishwashers.

• Do not put solvents in the appliance. Risk of explosion.

• Put the knives and all items with sharp points in the

cutlery basket with their points down. If not, put in a

horizontal position in the main basket.

• Use only branded products for dishwashers (detergent,

salt, rinse aid).

• If you open the door while the appliance is in opera-

tion, hot steam can escape. Risk of skin burns.

• Do not remove dishes from the dishwasher before the

end of the washing programme.

• When the washing programme is completed, discon-

nect the mains plug from the mains socket and close

the water tap.

• Only an authorised service engineer can repair this ap-

pliance. Use only original spare parts.

• Do not do repairs yourself to prevent injury and dam-

age to the appliance. Always contact your local Service

Force Centre.

General safety

General safetyGeneral safety

• Persons (including children) with reduced physical

sensory, mental capabilities or lack of experience and

knowledge must not use the appliance. They must have

supervision or instruction for the operation of the ap-

pliance by a person responsible for their safety.

• Obey the safety instructions from the manufacturer of

the dishwasher detergent to prevent burns to eyes,

mouth and throat.

• Do not drink the water from the dishwasher. Detergent

residues can stay in your appliance.

• Always close the door when you do not use the appli-

ance to prevent injury and not to stumble over the open

door.

• Do not sit or stand on the open door.

Child safety

Child safetyChild safety

• Only adults can use this appliance. Children must get

supervision to make sure that they do not play with the

appliance.

• Keep all the packaging away from children. There is a

risk of suffocation.

• Keep all detergents in a safe area. Do not let children

touch the detergents.

• Keep children away from the appliance when the door

is open.

Installation

InstallationInstallation

• Make sure that the appliance is not damaged because

of transport. Do not connect a damaged appliance. If

necessary, contact the supplier.

• Remove all packaging before first use.

• A qualified and competent person must do the electri-

cal installation.

• A qualified and competent person must do the plumb-

ing installation.

• Do not change the specifications or modify this prod-

uct. Risk of injury and damage to the appliance.

• Do not use the appliance:

– if the mains cable or water hoses are damaged,

– if the control panel, worktop or plinth area are dam-

aged, that you can get access to the inner side of the

appliance.

Contact your local Service Force Centre.

• Do not drill into the sides of the appliance to prevent

damage to hydraulic and electrical components.

Warning!

Warning!Warning! Carefully obey the instructions for

electrical and water connections.

Control panel

Control panelControl panel

1 2 3

5 4

1Programme knob

2Start/cancel button /(Cancel)

3Delay start button

4Indicator lights

5On/off indicator light

Indicator lights

Indicator lightsIndicator lights

Comes on when the washing phase or the rinsing phase operates.

Comes on when the drying phase operates.

Comes on when the washing programme is completed. Auxiliary functions:

• Level of the water softener.

• An alarm if the appliance has a malfunction.

Comes on when it is necessary to fill the salt container. Refer to 'Use of dishwasher salt'.

After you fill the container, the salt indicator light can continue to stay on for some hours. This does not have

an unwanted effect on the operation of the appliance.

1) When the salt container is empty, the related indicator light does not come on while a washing programme operates.

Delay start button

Delay start buttonDelay start button

Use the delay start button to delay the start of the washing

programme with an interval of 3 hours. Refer to the chap-

ter 'Setting and starting a washing programme'.

Programme knob and on/off indicator light

Programme knob and on/off indicator lightProgramme knob and on/off indicator light

• To set a washing programme, turn the programme

knob clockwise or anticlockwise. The programme

Product specificaties

Merk:	Zanussi
Categorie:	Vaatwasser
Model:	ZSF 2430
Apparaatplaatsing:	Aanrecht
Breedte:	545 mm
Diepte:	480 mm
Hoogte:	447 mm
Netbelasting:	1180 W
Aantal couverts:	6 couverts
Deurkleur:	Wit
Droogklasse:	B
Geluidsniveau:	53 dB
Waterconsumptie per cyclus:	7 l
Wasklasse:	A
Aantal wasprogramma's:	5
Kleur bedieningspaneel:	Wit
AC-ingangsspanning:	230 V
Snel wassen:	Ja
