Important to Know:

1.If you are not familiar with state and local electrical

codes, it is recommended that you consult with a

qualified electrician.

2.This fixture requires a 120 VAC, 60 Hz power

source.

3.For general safety and to avoid any possible

damage to the sensor, be sure the power is

switched "off" before adjustment.

Maximum Wattage: 24 W

Working Temperature Range: -13°F ~ 113°F

ASSEMBLY AND INSTALLATION

INSTRUCTIONS

NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.

2.READ AND SAVE THESE INSTRUCTIONS.

T0616 / T0617

Features:

WARNING:

TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF

POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.

Note: Fixture can be wall mounted or eave mounted.

Wall Mounted

Eave Mounted

1.Energy saving LED fixture.

2.

4.

Sensor

Backplate

Light Fixture

Fixture Mounting Screw

Decorative cover

Tools Needed:

1.Phillips-head screwdriver for attaching mounting screws to

mounting strap, mounting bracket and fixture to mounting bracket.

2.1/8” wide flat-head screwdriver for connecting the source wires

into the wiring terminal station on the mounting bracket.

(1) Philip-head Screwdriver

(2) 1/8" wide Flat-head Screwdriver

Photocell automatically keeps the light OFF during

daylight hours and automatically turns the light ON

during evening hours.

The light will DIM to low level brightness

automatically after 6 hours of evening illumination

The wall switch that the light is connected to can be

used to manually override and change functionality

and settings of certain modes.

Mounting

Strap

Outlet Box

Mounting Screw

Mounting Bracket

FRONT

Terminal

Station

L GND N

Mounting Bracket

Hole

Mounting Screw

Fixture Mounting

Screw Hole

3.

Hardware Package (included):

Mounting Screw X2

#8/32X1/2 in

Fixture Mounting Screw

Mounting Strap

Mounting Screw X2

#6/32 X1/2 in

Mounting Screw X2

#10/24 X1/4 in

Decorative cover
