Page 1/4
ASSEMBLY AND INSTALLATION
INSTRUCTIONS
WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
T0254 / T0255 / T0256 / T0257
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. Read and save these instructions.
Features
1. Energy saving fixture.
2. Use the dim-to-bright illumination option where
you want some minimum illumination through out
the night, such as at your front entrance or garage
door. Use the dark-to-bright illumination option
where you do not need minimum brightness, such
as the backyard or back porch.
3. When in manual override mode, use wall switch
to keep the light ON till dawn.
161107
Mounting Screw (B)
Green Grounding
Screw (C)
Lock Nut (F)
Wire Nut (E)
Ball Nut (G)
Rubber Pad (H)
Cross Bar (A)
Headless
Screw (D)
Important to Know
1. Read all instructions carefully before installation and
operation.
2. If you are not familiar with state and local electrical codes,
it is recommended that you consult with a qualified
electrician.
3. Before installation, shut off power at the main fuse or
circuit breaker box. Be aware that simply turning off the
wall switch is not sufficient to prevent an electrical shock.
4. This fixture requires a 120 VAC, 60 Hz power source.
5. Do not attempt to take the lantern apart; there are no
serviceable parts inside.
6. To avoid sensor damage by lightning or electrical surge,
make sure the grounding wire is securely connected.
7. For general safety and to avoid any possible damage to
the sensor, be sure the power is switched "off" before
replacing the bulb.
8. Compatible with LED dimmable bulb.
Maximum Wattage: 60W Incandescent Bulb or 20W
Dimmable LED Bulb.
Work Temperature: -4°F~104°F
Type A Max. 60W Bulb OR
Max. 20W Dimmable LED Bulb
(not include)
(not include)
Fixture
Back plate
Hardware Package (included):
Ball Nut (G)
Small Ball Nut
Rubber Pad (H)
Green Grounding Screw (C)
Outlet Box
Wire Nut (E)
Headless Screw (D)
Cross Bar (A)
Mounting Screw (B)
Lock Nut (F)
House Grounding Wire
Fixture Grounding Wire
Fixture Wire
