ASSEMBLY AND INSTALLATION
INSTRUCTIONS
T0729
Maximum Wattage: 60W Bulb
Working Temperature: -22°F~113°F
1. Read all instructions carefully before installation and
operation.
2. If you are not familiar with state and local electrical codes,
it is recommended that you consult with a qualified
electrician.
3. Before installation, shut off power at the main fuse or
circuit breaker box. Be aware that simply turning off the
wall switch is not sufficient to prevent an electrical shock.
4. This fixture requires a 120V AC, 60 Hz power source.
5. Do not attempt to take the lantern apart; there are no
serviceable parts inside.
6. To avoid sensor damage by lightning or electrical surge,
make sure the ground wire is securely connected.
7. For general safety and to avoid any possible damage to
the sensor, be sure the power is switched "off" before
replacing the bulb.
8. Compatible with most LED dimmable bulbs.
Hardware Package (included)：
Important to Know
Features
NOTE: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. Read
and save these instructions.
Page 1 / 5
1. Energy saving fixture.
2. When in manual override mode, use wall switch
to keep the light ON till dawn.
Mounting Screw (B)
Wire Connector (C)Set Screw (D)
Mounting Plate Unit (A)
Rubber Pad (E)
Mounting Screw (B)
Wire Connector (C)Set Screw (D)
Mounting Plate Unit (A)
Rubber Pad (E)
Fixture Ground Wire
Wire Connector (C)
Mounting Plate Unit (A)
House Ground Wire
Outlet Box
Fixture Wire
Set Screw (D)
Rubber Pad (E)
Backplate
Glass Shade
Mounting Screw (B)
Green Ground Screw
Max. 60W Type ST Bulb
(not included)
WARNING: Turn off the main power at circuit breaker before installing fixture.
231019
