1 947832

Issue 2

VIP-140A

IP Talkback Clean Room Ceiling Speaker

INTRODUCTION

The VIP-140A IP Talkback Clean Room Ceiling

Speaker enables voice access to a single zone of

one-way paging over an IP-based network. The

enclosure is made of steel with a durable white

powder coated finish. O-rings, washers and a

polycarbonate shield protect against dust incursion.

Power is provided to the VIP-140A via a Power over

Ethernet (PoE) switch meeting the 802.3af

specification.

SPECIFICATIONS

Access Methods

PBX, FXO Port w/VIP-811

POTS telephone set w/VIP-811

PBX, FXS Port w/VIP-821

Valcom M Cast Page Group

SIP – enabled telephone system

Features

RJ-45 network connection

Power over Ethernet (POE) 802.3af compatible

Large rubber O-ring to seal the grille to the

ceiling

Polycarbonate dust shield between the speaker

and grille

Rubber washers for all mounting hardware

INSTALLATION

FCC Information

This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when

the equipment is operated in a commercial

environment. This equipment generates, uses

and can radiate radio frequency energy and if

not installed and used in accordance with the

instruction manual, may cause harmful

interference to radio communications.

Operation of this equipment in a residential area

may cause harmful interference in which case

the user will be required to correct the

interference at his own expense.

DIMENSIONS/WEIGHT

13.0” Dia x 3.8” D

(33.0cm Dia. x 9.7cm D)

Weight: 2.5 lbs (1.13 kg)

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

Precautionary Designations

CAUTION: To reduce the risk of electric shock,

Do not remove cover.

No user serviceable parts inside.

Refer servicing to qualified service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

Packing List

Qty. Item

1 VIP-140A

1 VSP Document

Mounting Hardware
