1 947825

Issue 3

VE8001A, VE8001A- V4

VE8001, VE8001AR- ARV4

NETWORKED PAGE ZONE EXTENDER

INTRODUCTION

The VE8001A/VE8001ANetworked Page Zone R

Extender enables voice access to a single zone of

one-way paging over an IP-based LAN/WAN. This

allows page zone extension anywhere on the

network.The VE8001A is designed for wall or table

placement. The VE8001AR is designed for 19”

mounting (1UThe -V4 models are identical in t, ).

form and function to the non -V4 models.

SPECIFICATIONS

Features

• 1 Audio Input

• 2 Audio Outputs

• 2 Form C Relays

• 1 Contact Closure Input

• - jack for network connection RJ45

• Front panel activity LED

• Provides audio for up to 40 Valcom one-way

amplied speaker assemblies

• AUX audio input via RCA jack

• Contact closure or VOX operation of audio input

• Removable screw terminal connectors provided

for audio and relay interface

• AUX input music mutes during page

• Output control contact closure provided during

paging output

• Compatible with - or 70-Volt ampliers 25

• Barrel jack for optional DC power

• Power over Ethernet 802.3af Compatible

Dimensions/Weight

VE8001A, VE8001A-:V4

• H x 6.13" W x 5.25" D 1.38”

(3.50cm H x 15.6cm W x 13.33cm D)

•Weight: 1.25 lbs. (0.57 kg)

VE8001AR, VE8001AR-V4

• 1 Standard 19” Rack Unit

• 1.75” H x 16.50” W x 5.25” D

(4.45 cm x 41. cm x 13.33 cm) 91

•Weight: 5. lbs. (2. kg) 1032

VE8001A, VE8001A- V4

VE8001AR, VE8001AR- V4

Nominal Specications

Input Impedance: 600 Ohms

Input Level: -10dBm nominal

Voice Switch Sensitivity: -21dBm

Music Source Input Impedance: 8 to 600 Ohms

Music Input Level: -10dBm nominal

Output Impedance: 50 Ohms

Output Level: - 10dBm nominal

Relay Current: 1 Amp @ 24VDC

Nominal Power Requirements

Via rear panel barrel connector:

Voltage: 24VDC

Current: 325mA

Via 802.3af PoE Ethernet Switch:

802.3af: Class 3

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating
