PAGE 1 OF 6 1125 IH-11049

STAINLESS STEEL WALL MOUNT

EYEWASH STATION

1-800-295-5510

uline.com

H-11049

TOOLS NEEDED

1/2" Diameter

Masonry Drill Bit

Eye ProtectionHammerSocket

Wrench

Drill

INSTALLATION

1. Verify the eyewash station is positioned in the

desired location. Mark the wall where holes will be

drilled.

WARNING! Wear eye protection when

completing step 2.

2. Using a 1/2" diameter masonry drill bit, drill a hole

approximately 3⁄" deep into wall. (See Figure 1)

NOTE: For the anchor to function properly, the

hole must not be larger in diameter than the

anchor bolt.

3. Clean out debris and dust from inside the hole. Fully

insert the anchor bolt through the mounting plate

and into the hole.

NOTE: Thread washers and nut onto anchor

bolt. Nut should be tightened halfway between

end of bolt and top of anchor sleeve.

(See Figure 2)

4. Slightly tap down the anchor bolt with a hammer if

needed. Tighten the hex nut with socket wrench until

the anchor bolt is secure. (See Figure 3)

5. Repeat for remaining anchors.

XX

Figure 2

Figure 3

Tighten

halfway

Not all the

way tight

Not all the

way loose

Figure 1

Anchor Bolt

1/2" Masonry

Drill Bit

Para Español, vea páginas 3-4.

Pour le français, consulter les pages 5-6.
