PAGE 1 OF 6 0421 IH-9459

H-9459

EYEWASH DRENCH HOSE –

DECK MOUNT

1-800-295-5510

uline.com

PARTS

TOOLS NEEDED

Electric

Drill

8' Hose x 1Handle x 1Squeeze

Valve x 1

Deck Flange x 145º Panel Flange x 1

1/4" Drill Bit

Spray Head x 2

SAFETY

CAUTION! In the event of a chemical splash or

spill, affected area of the victim's body must

be flushed immediately for at least 15 minutes.

For chemical spills to the eyes, user should

hold eyes open as wide as possible to permit

water to reach all areas around the eye.

CAUTION! Rinsing affected area for 15 minutes

is only the first step in treating exposure to a

hazardous chemical. Following rinsing, victim

should be examined and treated by a doctor

or other trained medical specialist as soon as

possible.

INSTALLATION

NOTE:

Unit should be installed by licensed

plumber.

NOTE:

Thoroughly clean and flush supply line

prior to installing unit. Pipe shavings, scale,

tape and other debris can be carried through

a pipe and into unit when system is activated.

This debris can damage valve components

and interfere with proper operation of the valve.

• The water supply line should have outside diameter

of at least 1/2" and should be copper or other

corrosion-resistant material.

• Unit requires a 1⁄" diameter mounting hole. Hole

should be large enough to accommodate the

shank on the deck flange but not allow excessive

lateral movement. Minimizing the hole size provides

as large a surface as possible to secure the locknut.

• Unit has a 3/8" NPT male thread on inlet.

(See Figure 1) Use Teflon® tape or other pipe sealant

to seal thread. Do not apply sealant in a way that

will allow it to enter into unit.

Figure 1

Deck Flange with

Handle Locator Guides

Inlet3/8" NPT

Male

Thread

Shank

Locknut

Para Español, vea páginas 3-4.

Pour le français, consulter les pages 5-6.
