AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,

intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.

MSP430F67791

,

MSP430F67781

,

MSP430F67771

,

MSP430F67761

,

MSP430F67751

MSP430F67691

,

MSP430F67681

,

MSP430F67671

,

MSP430F67661

,

MSP430F67651

MSP430F67491,MSP430F67481,MSP430F67471,MSP430F67461,MSP430F67451

SLAS815D–NOVEMBER2012–REVISEDSEPTEMBER2018

MSP430F677x1,MSP430F676x1,MSP430F674x1PolyphaseMeteringSoCs

1DeviceOverview

1

1.1Features

1

•Accuracy<0.1%Over2000:1DynamicRangefor

PhaseCurrent

•MeetsorExceedsANSIC12.20andIEC62053

Standards

•SupportforMultipleSensorsSuchasCurrent

Transformers,RogowskiCoils,orShunts

•PowerMeasurementforuptoThreePhasesPlus

Neutral

•DedicatedPulseOutputPinsforActiveand

ReactiveEnergyforCalibration

•Four-QuadrantMeasurementperPhaseor

Cumulative

•ExactPhaseAngleMeasurements

•DigitalPhaseCorrectionforCurrentTransformers

•TemperatureCompensatedEnergyMeasurements

•40-Hzto70-HzLineFrequencyRangeUsing

SingleCalibration

•FlexiblePowerSupplyOptionsWithAutomatic

Switching

•DisplayOperatesatVeryLowPowerDuringAC

MainsFailure:3µAinLPM3

•LCDDriverWithContrastControlforupto320

Segments

•Password-ProtectedReal-TimeClock(RTC)With

CrystalOffsetCalibrationandTemperature

Compensation

•IntegratedSecurityModulestoSupportAnti-

Tamper

•MultipleCommunicationInterfacesforSmartMeter

Implementations

•High-Performance25-MHzCPUWith32-Bit

Multiplier

•WideInputSupplyVoltageRange:

3.6VDownto1.8V

•Ultra-LowPowerConsumptionDuringEnergy

Measurement

–2.9mWat10-MHzOperation(3V)

•MultipleLow-PowerModes

–StandbyMode(LPM3):2.1µAat3V,

WakeupinLessThan5µs

–RTCMode(LPM3.5):0.34µAat3V

–ShutdownMode(LPM4.5):0.18µAat3V

•Upto512KBofSingle-CycleFlash

•Upto32KBofRAMWithSingle-CycleAccess

•UptoSevenIndependent24-BitSigma-Delta

ADCsWithDifferentialInputsandVariableGain

•System10-Bit200-kspsADC

–SixChannelsPlusSupplyandTemperature

SensorMeasurement

•SixEnhancedCommunicationsPorts

–ConfigurableAmongFourUART,SixSPI,and

TwoI²CInterfaces

•Four16-BitTimersWithNineTotal

Capture/CompareRegisters

•128-PinLQFP(PEU)PackageWith90I/OPins

•100-PinLQFP(PZ)PackageWith62I/OPins

•IndustrialTemperatureRangeof–40°Cto85°C

•3-PhaseElectronicWatt-HourMeterDevelopment

Tool(AlsoSeeToolsandSoftware)

–EVM430-F6779WithApplicationNote

–EnergyMeasurementDesignCenterfor

MSP430™MCUs

1.2Applications

•3-PhaseElectronicWatt-HourMeters

•UtilityMetering

•EnergyMonitoring
