LM140QML
www.ti.com
SNVS382B–FEBRUARY2006–REVISEDMAY2013
LM140QMLThreeTerminalPositiveRegulators
CheckforSamples:LM140QML
1
FEATURES
DESCRIPTION
Themonolithic3-terminalpositivevoltageregulators
2
•CompleteSpecificationsat1.0Aand0.5A
employinternalcurrent-limiting,thermalshutdown
Loads
andsafe-areacompensation,makingthem
•NoExternalComponents
essentiallyindestructible.Ifadequateheatsinkingis
•InternalThermalOverloadProtection
provided,theycandeliverover0.5Aoutputcurrent.
Theyareintendedasfixedvoltageregulatorsina
•InternalShortCircuitCurrent-Limiting
widerangeofapplicationsincludinglocal(on-card)
•OutputTransistorSafe-AreaCompensation
regulationforeliminationofnoiseanddistribution
problemsassociatedwithsingle-pointregulation.In
additiontouseasfixedvoltageregulators,these
devicescanbeusedwithexternalcomponentsto
obtainadjustableoutputvoltagesandcurrents.
Considerableeffortwasexpendedtomaketheentire
seriesofregulatorseasytouseandminimizethe
numberofexternalcomponents.Itisnotnecessaryto
bypasstheoutput,althoughthisdoesimprove
transientresponse.Inputbypassingisneededonlyif
theregulatorislocatedfarfromthefiltercapacitorof
thepowersupply.
ConnectionDiagram
Figure1.SteelMetalCanTO-39Package(NDT)Figure2.TO-3MetalCan(K)
BottomViewBottomView
SeePackageNumberNDT0003ASeePackageNumberK0002C
Thesedeviceshavelimitedbuilt-inESDprotection.Theleadsshouldbeshortedtogetherorthedeviceplacedinconductivefoam
duringstorageorhandlingtopreventelectrostaticdamagetotheMOSgates.
1
Pleasebeawarethatanimportantnoticeconcerningavailability,standardwarranty,anduseincriticalapplicationsof
TexasInstrumentssemiconductorproductsanddisclaimerstheretoappearsattheendofthisdatasheet.
2Alltrademarksarethepropertyoftheirrespectiveowners.
PRODUCTIONDATAinformationiscurrentasofpublicationdate.
Copyright©2006–2013,TexasInstrumentsIncorporated
ProductsconformtospecificationsperthetermsoftheTexas
Instrumentsstandardwarranty.Productionprocessingdoesnot
necessarilyincludetestingofallparameters.
