bq3060

SLUS928B–MARCH2009–REVISEDJULY2016

bq3060SBS1.1-CompliantGasGaugeandProtectionWithCEDV

1

1Features

1

•AdvancedCEDV(CompensatedEnd-of-Discharge

Voltage)Gauging

•FullyIntegrated2,3,and4SeriesLi-IonorLi-

PolymerCellBatteryPackManager

•8-BitRISCCPUWithUltra-LowPowerModes

•FullArrayofProgrammableProtectionFeatures

–Voltage,Current,andTemperature

•SHA-1Authentication

•FlexibleMemoryArchitectureWithIntegrated

FlashMemory

•SupportsTwo-WireSMBusv1.1InterfaceWith

High-speed400kHzProgrammingOption

•P-CHHighSideProtectionFETDrive

•LowPowerConsumptionSleepMode:<69μA

•High-AccuracyAnalogFrontEndWithTwo

IndependentADCs

–High-Resolution,15~22-bitIntegratorfor

CoulombCounting

–16-BitDelta-SigmaADCWitha16-Channel

MultiplexerforVoltage,Current,and

Temperature

•UltraCompactPackage:24-PinTSSOPPW

2Applications

•NetbookandNotebookPCs

•MedicalandTestEquipment

•PortableInstruments

3Description

TheTexasInstrumentsbq3060BatteryManagerisa

fullyintegrated,single-chip,pack-basedsolutionthat

providesaricharrayoffeaturesforgasgauging,

protection,andauthenticationfor2,3,or4seriescell

Li-Ionbatterypacks.Withafootprintofmerely7.8

mm×6.4mminacompact24-pinTSSOPpackage,

thebq3060maximizesfunctionalityandsafetywhile

dramaticallycuttingthesolutioncostandsizefor

smartbatteries.

Usingitsintegratedhigh-performanceanalog

peripherals,thebq3060measuresandmaintainsan

accuraterecordofavailablecapacity,voltage,

current,temperature,andothercriticalparametersin

Li-IonorLi-Polymerbatteries,andreportsthe

informationtothesystemhostcontrolleroveran

SMBus1.1-compatibleinterface.

Thebq3060providessoftware-firstlevelandsecond

levelsafetyprotectiononovervoltage,undervoltage,

overtemperature,andovercharge,aswellas

hardware-overcurrentindischarge,shortcircuitin

charge,anddischargeprotection.

DeviceInformation

(1)

PARTNUMBERPACKAGEBODYSIZE(NOM)

bq3060TSSOP(24)4.4mm×7.8mm

(1)Forallavailablepackages,seetheorderableaddendumat

theendofthedatasheet.

SystemPartitioningDiagram
