ADC11DV200
www.ti.com
SNAS477A–APRIL2009–REVISEDAPRIL2013
ADC11DV200Dual11-bit,200MSPSLow-PowerA/DConverterwithParallelLVDS/CMOS
Outputs
CheckforSamples:ADC11DV200
1
FEATURES
DESCRIPTION
TheADC11DV200isamonolithicanalog-to-digital
2
•Single1.8VPowerSupplyOperation.
convertercapableofconvertingtwoanaloginput
•PowerScalingwithClockFrequency.
signalsinto11-bitdigitalwordsatratesupto200
•InternalSample-and-Hold.
MegaSamplesPerSecond(MSPS).Thedigital
outputmodeisselectableandcanbeeither
•InternalorExternalReference.
differentialLVDSorCMOSsignals.Thisconverter
•PowerDownMode.
usesadifferential,pipelinedarchitecturewithdigital
•OffsetBinaryor2'sComplementOutputData
errorcorrectionandanon-chipsample-and-hold
Format.
circuittominimizediesizeandpowerconsumption
whileprovidingexcellentdynamicperformance.A
•LVDSorCMOSOutputSignals.
uniquesample-and-holdstageyieldsafull-power
•60-PinWQFNPackage,(9x9x0.8mm,0.5mm
bandwidthof900MHz.FabricatedincoreCMOS
Pin-Pitch)
process,theADC11DV200maybeoperatedfroma
•ClockDutyCycleStabilizer.
single1.8Vpowersupply.TheADC11DV200
achievesapproximately10.06effectivebitsatNyquist
•IFSamplingBandwidth>900MHz.
andconsumesjust280mWat170MSPSinCMOS
mode450mWat200MSPSinLVDSmode.The
APPLICATIONS
powerconsumptioncanbescaleddownfurtherby
•DigitalPredistortion(DPD)
reducingsamplingrates.
•WirelessCommunicationsInfrastructure
•MedicalImaging
•PortableInstrumentation
•DigitalVideo
KEYSPECIFICATIONS
•Resolution:11Bits
•ConversionRate:200MSPS
•ENOB:10.06bits(typ)@Fin=70MHz
•SNR:62.5dBFS(typ)@Fin=70MHz
•SINAD:62.3dBFS(typ)@Fin=70MHz
•SFDR:82dBFS(typ)@Fin=70MHz
•LVDS:Power450mW(typ)@Fs=200MSPS
•CMOS:Power280mW(typ)@Fs=170MSPS
•OperatingTemp.Range:−40°Cto+85°C.
1
Pleasebeawarethatanimportantnoticeconcerningavailability,standardwarranty,anduseincriticalapplicationsof
TexasInstrumentssemiconductorproductsanddisclaimerstheretoappearsattheendofthisdatasheet.
2Alltrademarksarethepropertyoftheirrespectiveowners.
PRODUCTIONDATAinformationiscurrentasofpublicationdate.
Copyright©2009–2013,TexasInstrumentsIncorporated
ProductsconformtospecificationsperthetermsoftheTexas
Instrumentsstandardwarranty.Productionprocessingdoesnot
necessarilyincludetestingofallparameters.
