ADC1175
www.ti.com
SNAS012H–JANUARY2000–REVISEDAPRIL2013
ADC11758-Bit,20MHz,60mWA/DConverter
CheckforSamples:ADC1175
1
FEATURES
DESCRIPTION
TheADC1175isalowpower,20Mspsanalog-to-
2
•InternalSample-and-HoldFunction
digitalconverterthatdigitizessignalsto8bitswhile
•Single+5VOperation
consumingjust60mWofpower(typ).TheADC1175
•InternalReferenceBiasResistors
usesauniquearchitecturethatachieves7.5Effective
Bits.Outputformattingisstraightbinarycoding.
•IndustryStandardPinout
•TRI-STATEOutputs
TheexcellentDCandACcharacteristicsofthis
device,togetherwithitslowpowerconsumptionand
+5Vsinglesupplyoperation,makeitideallysuitedfor
APPLICATIONS
manyvideo,imagingandcommunications
•VideoDigitization
applications,includinguseinportableequipment.
•DigitalStillCameras
Furthermore,theADC1175isresistanttolatch-up
andtheoutputsareshort-circuitproof.Thetopand
•PersonalComputerVideoCameras
bottomoftheADC1175'sreferenceladderis
•CCDImaging
availableforconnections,enablingawiderangeof
•Electro-Optics
inputpossibilities.
TheADC1175isofferedinaTSSOP.Itisdesigned
KEYSPECIFICATIONS
tooperateoverthecommercialtemperaturerangeof
•Resolution8Bits
-20°Cto+75°C.
•MaximumSamplingFrequency20Msps(min)
•DNL0.75LSB(max)
•ENOB7.5Bits(typ)
•EnsuredNoMissingCodes
•PowerConsumption(excludingI
REF
)60mW
(typ)
PINCONFIGURATION
ADC1175PinConfiguration
TSSOPPackage
SeePackageNumberPW
1
Pleasebeawarethatanimportantnoticeconcerningavailability,standardwarranty,anduseincriticalapplicationsof
TexasInstrumentssemiconductorproductsanddisclaimerstheretoappearsattheendofthisdatasheet.
2Alltrademarksarethepropertyoftheirrespectiveowners.
PRODUCTIONDATAinformationiscurrentasofpublicationdate.
Copyright©2000–2013,TexasInstrumentsIncorporated
ProductsconformtospecificationsperthetermsoftheTexas
Instrumentsstandardwarranty.Productionprocessingdoesnot
necessarilyincludetestingofallparameters.
