Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: September 5, 2024
Product ID
8NS8-RACK-MOUNT-PDU
Product Diagram
Front
8-Outlet 1U Rack-Mount PDU - Individual Outlet Switches - Circuit Breaker
ComponentFunction
1Circuit Breaker
• Turns-O All Power, in the Event of a Power Surge
• 15A Tripping Point
• Push to Reset
2
Power Switches with
LEDs & Switch Covers
(x8)
• Turns the Corresponding Outlet On or O
• Remove Cover to Access Switch
• Illuminates Red When the Corresponding
Outlet is Turned On
3
Outlets
(x8)
• Connects to an AC Input on Downstream Device(s)
• NEMA 5-15R Connector
• 125V AC / 15A
4Built-in Power Cable
• Connect to an AC Power Source
• NEMA 5-15P Connector
• 125V AC / 15A
5
Built-in 19in Mounting
Brackets (x2)
• Mounts the PDU into 1U of Rack Space
• EIA-310 Compliant
1
Package Contents
• Rack-Mount PDU x 1
• Quick-Start Guide x 1
Requirements
• Available AC Power Source (NEMA 5-15R Outlet)
• Available 1U of EIA-310 Compliant Rack Space
• 4x Cage Nuts (If the 1U of Rack-Space Features Square Mounting Holes)
• 4x Cabinet Screws
For the latest drivers, manuals, product information, technical specications, and
declarations of conformance, please visit: www.StarTech.com/8NS8-RACK-MOUNT-PDU
Rear
2
3
4
5
5
