Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: September 17, 2024

Product ID

8NM8-RACK-MOUNT-PDU

12NM8-RACK-MOUNT-PDU

16NM8-RACK-MOUNT-PDU

Front

Rear

Package Contents

• Metered PDU x 1

• Quick-Start Guide x 1

Requirements

• Available AC Power Source (NEMA 5-15R Outlet)

• Available 1U of EIA-310 Compliant Rack Space

• 4x Cage Nuts (If the 1U of Rack-Space Features Square Mounting Holes)

• 4x Cabinet Screws

For the latest drivers, manuals, product information, technical specications, and

declarations of conformance, please visit:

www.StarTech.com/8NM8-RACK-MOUNT-PDU

www.StarTech.com/12NM8-RACK-MOUNT-PDU

www.StarTech.com/16NM8-RACK-MOUNT-PDU

1U Rack-Mount Metered PDU with LCD Display & Surge Protection

ComponentFunction

1

LCD Display

(Orange Backlight)

• Displays real-time Volts, Amps, Watts, and

Power Factor

2

Protection Present

LED

• Solid Green: Surge Protection is active

• O: Surge Protection is o or damaged

3Outlets

• Connects to an AC Input on Downstream Device(s)

• NEMA 5-15R Connector

• 125V AC / 15A

4

Circuit Breaker

(With Switch Guard)

• Turns o All Power, in the event of a Power Surge

• 15A Tripping Point

• Push to Reset

5

Built-in 19in Mounting

Brackets (x2)

• Mounts the Metered PDU into 1U of Rack Space

• EIA-310 Compliant

6Built-in Power Cable

• Connect to an AC Power Source

• NEMA 5-15P Connector

• 125V AC / 15A

1

3

6

5

5

3

4

2

*12NM8-RACK-MOUNT-PDU shown
