VS-123010

VS-123011

VS-123014

VS-122007

Apply Teflon Tape in a clockwise direction to all

threaded connections.

1

2

3

4

5

6

NOTE: Inspect Diverter to be sure Sealing

Washer is in place within Coupling Nut.

Thread Coupling Nut of Diverter onto Shower

Arm. Tighten with Adjustable Wrench.

Thread Fixed Showerhead onto front outlet of

Diverter. Tighten with Adjustable Wrench.

Thread Hose end marked “HAND SHOWER”

onto base of Handheld Shower. Hand tighten

connection.

Mount ADA Slide Bar in desired position using

installation instructions included with product.

Refer to rough-in drawing for critical mounting

dimensions.

Adjustable

Wrench

Teflon

Tape

Keep your Speakman product looking new by

cleaning it periodically with a soft cloth. Avoid

abrasive cleaners, steel wool, and harsh chemicals

as these will dull the finish and void your warranty.

This item is NOT designed for use as a grab bar.

Do not mount in locations where product is likely

to be used as a grab bar.

Cover your drain to prevent loss of parts.

Be sure to read instructions thoroughly before

beginning installation. Do not overtighten any

connections or damage may occur.

Thread Hose end marked “VACUUM BREAKER”

onto bottom outlet of Diverter. Hand tighten

connection.

VS-12XXXX-IOM-R1

NOTE: Showerhead

appearance may

differ depending on

model number.
