INSTRUCTIONS FOR MODELS
92-S-4000-04
For additional assistance or service please contact:
SPEAKMAN
®
Company
400 Anchor Mill Road
New Castle, DE 19720
800-537-2107
customerser[email protected]
www.speakman.com
S-4000 -E2 -E175 -E15
S-4001 -E2 -E175 -E15
S-4002 -E2 -E175 -E15
TOOLS AND SUPPLIES
IMPORTANT
SAFETY TIPS
Cover your drain to prevent loss of parts.
MAINTENANCE
WARRANTY
Additional warranty information can be found at:
www.speakman.com
Adjustable
Wrench
Be sure to read instructions thoroughly before
beginning installation. Do not overtighten any
connections or damage may occur.
Periodic cleaning using a mild soap and warm water
will help keep your Showerhead's appearance in its
original condition.
For best results, dry immediately with a soft, clean
cloth. DO NOT USE harsh and/or abrasive cleaners.
In certain water conditions, mineral deposits may
form. To remove these deposits, it is recommended
that you soak the shower head in a solution of 2 parts
vinegar to 1 part water for one hour. Rinse thoroughly
with fresh water. Brush off any remaining mineral
deposits from the spray channels.
Thread Seal
Tape
(INCLUDED)
1
Apply Thread Seal Tape to the outlet side
of shower arm in a clockwise direction.
2
Thread Showerhead onto shower arm by
turning it in a clockwise direction. Tighten
with adjustable wrench. Turn water supply
on and check for leaks.
ROUGH IN DIMENSIONS
2
5
1
"
140mm
3
1
8
"
80mm
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
Inlet:
½” NPT Female
Standard Model Flow Data:
Max Flow Rate: 2.5 gpm (9.5 L/min)
FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED
AT 7.6 L/MIN (2.0 GPM) OR LESS.
E2 Model Flow Data:
Max. Flow Rate: 2.0 gpm (7.6 L/min)
Min. Flow Rate: 1.5 gpm (5.7 L/min) @ 45psi
FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED
AT 6.6 L/MIN (1.75 GPM) OR LESS.
E175 Model Flow Data:
Max. Flow Rate: 1.75 gpm (6.6 L/min)
Min. Flow Rate: 1.3 gpm (4.9 L/min) @ 45psi
FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED
AT 5.7 L/MIN (1.5 GPM) OR LESS.
E15 Model Flow Data:
Max. Flow Rate: 1.5 gpm (5.7 L/min)
Min. Flow Rate: 1.1 gpm (4.2 L/min) @ 45psi
FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED
AT 5.2 L/MIN (1.37 GPM) OR LESS.
