INSTRUCTIONS FOR MODELS
92-S-5002-01
For additional assistance or service please contact:
SPEAKMAN
®
800-537-2107
customerser[email protected]
www.speakman.com
S-5002-E2
S-5002-E175
S-5002-E15
TOOLS AND SUPPLIES
IMPORTANT
SAFETY TIPS
Cover your drain to prevent loss of parts.
MAINTENANCE
WARRANTY
Warranty information can be found at:
www.speakman.com
Thread Seal
Tape
(included)
Adjustable
Wrench
Be sure to read instructions thoroughly before
beginning installation. Do not overtighten any
connections or damage may occur. This showerhead
has an operating range of 20-80 psi.
Periodic cleaning using a mild soap and warm water
will help keep your Showerhead's appearance in its
original condition.
For best results, dry immediately with a soft, clean
cloth. DO NOT USE harsh and/or abrasive cleaners.
To help restore the finish, occasionally apply a
non-abrasive wax to your showerhead body (follow
manufacturers’ instructions).
On CHROME PLATED SHOWER HEADS, a two (2)
part white vinegar, one (1) part water solution can be
used to break down excessive mineral deposits on the
sprays. Let the showerhead soak in the solution for
about ½ hour then rinse thoroughly. Brush off any
remaining mineral deposits if necessary.
DO NOT USE the vinegar/water treatment on any
finish other than Chrome.
To reduce mineral build-up, turn the handle to RAIN
position to let the water drain out after every use.
ROUGH IN DIMENSIONS
Specifications:
Inlet: 1/2” NPT FEMALE
Model:S-5002-E15
Max. Flow Rate:1.5 gpm (5.7 L/min)
Min. Flow Rate:1.3 gpm (4.9 L/min) @ 45psi
FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED
AT 4.9 L/MIN (1.3 GPM) OR LESS.
Model:S-5002-E2
Max. Flow Rate:2.0 gpm (7.6 L/min)
Min. Flow Rate:1.75 gpm (6.6 L/min) @ 45 psi
FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED
AT 6.6 L/MIN (1.75 GPM) OR LESS.
Model:S-5002-E175
Max. Flow Rate:1.75 gpm (6.6 L/min)
Min. Flow Rate:1.50 gpm (5.7 L/min) @ 45 psi
FOR USE WITH AUTOMATIC COMPENSATING VALVES RATED
AT 5.7 L/MIN (1.50 GPM) OR LESS.
1
Apply Thread Seal Tape to the outlet side of
shower arm in a clockwise direction.
2
Thread Shower head onto shower arm by turning
it in a clockwise direction. Tighten with adjustable
wrench. Turn water supply on and check for leaks.
3
Rotate Spray Face to change Spray Settings.
