1/11

923186-

Rev. 2

SPEAKMAN COMPANY

S- Installation, Operation & Maintenance Instructions3011

ANYSTREAM

®

SHOWERHEAD

DESCRIPTION

Polished chrome plated ANYSTREAM

®

S-3011 Showerhead with a 4-1/2” outer spray adjustment ring. 5 self-

cleaning plunger nozzles resist scale bui- spray streams for a full body coverage pattern. The ldup and provide45

center core nozzle delivers twelve massaging jets and a combination spray is included. Water conserving pressure

compensating AUTOFLO® device reduces ow to 2.5 GPM/9.46LPM maximum, to meet existing ANSI A112.18.1

Standard. ½” NPT inlet.

SPECIFICATIONS

SUPPLY INLET: ½” NPT

FLOW RATE: 2.5 GPM/9.46LPM MAXIMUM

SHIPPING WEIGHT: 1.0 LBS.

INSTALLATION

Remove the old shower head from the shower arm. Clean o any debris on the threads of the shower arm. Wrap

Teon tape around the shower arm threads in a clockwise direction. Turning in a clockwise direction, screw the new

Speakman shower head onto the shower arm. Tighten with a wrench. Turn the water supply on and check for leaks.

OPERATION

To adjust the spray pattern of the shower head, simply rotate the outer ring to the desired spray (Full-Body, Dual

action or Massage). The outer ring can rotate 360°.

MAINTENANCE

The gleaming nish of your SPEAKMAN ANYSTREAM

®

shower head can be cleaned by using mild soap and warm

water. Dry immediately with a soft, clean cloth for best results. The ow control device limits water ow to 2.5 gallons

per minute. The small orices may become clogged with scale and other minerals found in potable water. To clean

the flow regulator, simply remove the shower head from the bent arm, dislodge the flow regulator which is located in

the inlet and clean as necessary.

BN –Brushed Nickel

S--E2 3011–Low Flow Showerhead

(2.0 GPM/ 7.6 LPM)

S---E2 3011BN–Low Flow Brushed

Nickel Showerhead

(2.0 GPM/ 7.6 LPM)

Product improvements may

cause specication and

dimensional changes without

notice.

OPTIONS

ROUGH-IN MEASUREMENTS

S

S

S

SSP

P

P

PPE

E

E

EEA

A

A

AAK

K

K

KKM

M

M

MMA

A

A

AAN

N

N

NN

PO Box 191 Wilmington, DE 19899 Phone: 800--2107 Fax: 800-- 5379772747

Visit us on the web at www.speakmancompany.com
