The CB612B Balancing Wiring Center brings smarter control to multi-

zone heating systems. Its intelligent balancing algorithm optimizes heat

distribution by limiting how many actuators operate at the same time,

Classical and Balancing modes, helping to protect the system, reduce wear,

and ensure reliable long-term performance.

Introduction

This product complies with the essential requirements and other relevant

provisions of Directives GPSR 2023/988, RED 2025/138, SVHC 251 (REACH)

and RoHS 2015/863 and 2017/2102 amending Annex II to Directive 2011/65/

EU of the European Parliament and of the Council on the restriction of the

use of certain hazardous substances in electrical and electronic equipment.

The full text of the EU Declaration of Conformity is available at the following

internet address: www.saluslegal.com.

2405-2480MHz, <20dBm

Product Compliance

Use in aordance to national and EU regulations. Use the device as intended, cc

keeping it in dry condition. Product for indoor use only. Installation must

regulations.

Safety Information

Unscrew the screws by

turning them a quarter

turn counterclockwise.

Using a screwdriver, unscrew the main housing at the points indicated.

CB612B

EN

Manufacturer:

SALUS Controls plc

Forge Way, Parkgate Rotherham, S60 1SD, UK

MANUAL

BALANCING

WIRING CENTRE

QUICK GUIDE

SALUS Controls is a member of the Computime Group.

Maintaining a policy of continuous product development

design and materials of products listed in this brochure

without prior notice.

03/2026

www.saluscontrols.com

Importer:

Salus Controls

European Distribution sp.z o.o. ul. Szamocka 8,

piętro 6. 01 748 Warszawa, Poland

UK: [email protected]

DE: [email protected]

PL: [email protected]

FR: [email protected]

RO: [email protected]o

DK: Support@salus-controls.dk

This product is compatible with a wide range of devices, including

thermostats, actuators, and the optional PL06 pump logic module, ensuring

Compatibility

Box Content

Installation

A

B

D

E

LN

min

NachlaufzeitP1

40556

23

1235

6

987

4

Thermostats connection

3

Power Supply

2

Cartridge fuse 5 x 20 mm 10 A

1

PL06 - pump logic module (optional)

6

Serial connector for PL06

5

* (Night Set Back reduction) functionNSB

4

*Status LEDs

9

8

Actuators connection

7

*

NSB (Night Setback)

periods (typically at night or when the building is unoccupied) to reduce energy consumption. When the NSB

terminal is active, the system operates at a reduced temperature instead of the normal comfort setpoint.

4

- green LED device is powered (230 V AC)

- green LED local WiFi Network active

- orange LED

function activeNSB

**

9

CB612B

(Wiring Centre)

Quick Guide

8 x Screws for

Pressing BarPressing Bar

2 x Wall

Anchors

2 x Wall

Mounting Screws

Fix the back of the housing to the wall. For DIN-rail mounting, open the

hooks on the rear of the housing.

Strip the cables at recommended length.

Route rnea unthewies underththe motistng rapthe at rear othef wiring

centre. T l hesetincudesadditionl aacco to awhnessriesssist it isttiallaon.

Wires for actuators

(min. 2 x 0,75 mm2 230 V

max. 2 x 1,5 mm2 230 V)

50 mm

Wires for pump control

and power supply

(min. 3 x 1,0 mm2 230 V,

max. 3 x 1,5 mm2 230 V)

110 mm

12 mm

12 mm

Thermostats wires

(min. 4 x 0,75 mm2 230 V

max. 4 x 1,5 mm2 230 V)

C
