Features

USB Type-C Male (Connect to a host computer)

Rocstor introduces Type-C 4-in-1 hub: Featuring HDMI, USB-A, RJ45, and a Type-C

female port, oering an optimal solution for expanding the port options of

Type-C/Thunderbolt 3 hosts (PC/Laptop/Mobile phone, etc.), especially benecial for

those with a single Type-C port. Equipped with the latest DP1.4 Alt mode supported

IC, this hub enables HDMI video output at a maximum resolution of 4k/60Hz while

simultaneously transferring USB 3.1 data at a maximum speed of 5Gbps. The RJ45 port

facilitates access to super-fast Ethernet networks for the host. Additionally, the Type-C

female port supports PD 3.0 with a maximum power delivery of 100W when

connected to a PD Adapter and facilitates data transmission at a maximum speed of

5Gbps when connected to a Type-C device. Compatible with all DP Alt mode

supported Type-C hosts, this hub ensures seamless compatibility and enhanced

functionality.

Before attempting to use this unit, please check the packaging and make sure the

following items are contained in the packaging:

• Main Unit x1

• User Manual

HDMI

• Supports HDMI max 4K/60Hz， 4：4：4,

8bit with 18Gbps Bandwidth

• Supports 6/8/10/12 bit color depth

output

• Supports output pixel format

RGB4:4:4/YCbCr4:4:4/YCbCr4:2:2

• Supports HDCP 2.2&HDCP1.4

• Supports HDR

Note:When connecting a DP1.4 Alt mode

supported host, the max resolution of

HDMI is 4k/60Hz; When connecting a

DP1.2 Alt mode supported host, the max

resolution of HDMI is 4k/30Hz due to

bandwidth limitation

Upstream:

Downstream:

• Supports DP1.4 Alt mode, downward compatible with DP1.2 Alt mode

Note:To get max bandwidth, the host should support DP1.4 Alt mode with DSC format

USB-A X1

• Support max 7.5W([email protected])

downstream charging

• Max 5Gbps bandwidth

RJ45 X1

• Supports Gigabit

Ethernet,10M/100M/1000M

• Supports Wake-On-LAN

• Supports full duplex ow control

• Light indicates the state, no

light when no Internet connected,

orange light turns on when network

connection is established, yellow light

ashes when transmitting data

Type-C Female X1

(for PD Charging & Data)

When connecting a PD Adapter:

• Support PD Charging 100W (20V/5A)

• Support Fast Role Swap of PD 3.0, the

connected device will not get

disconnected while plugging in and out

PD Adapter

• 7.5W is dedicated to the functioning of

this product, the rest power (max 92.5W)

will be passed to charge for the host

When connecting a Type-C device:

• Max 5Gbps data transfer

• Max 7.5w(5V/1.5A) downstream charging

• Share max 7.5W downstream charging

with USB-A port

Package Contents

Specication

Input

OutputHDMI Female p1-x1

USB-A Female x1

RJ45 x1

Type-C Female p1-x1 (PD & Data)

USB-C Male x1

3 Years

Operating Temperature

Storage Humidity

Storage Temperature

Operating Humidity

0°C to 45°C (32°F to 113°F)

10% to 90 % RH (no condensation)

-10°C to 70°C (14°F to 158°F)

10% to 90% RH (no condensation)

Introduction

Environmental

Input / Output Connector

CerticationsFCC, CE

Regulatory Approvals

User ManualEnglish Version

Accessory Adapter

Warranty

Limited Warranty

Operating Temperature

Operating Temperature

Size

0°C to 45°C (32°F to 113°F)

4.3x1.9x0.6in - (110x50x16.2mm)

Mechanical

Weight2.4lbs - (75g)

Power Supply

100W(20V/5A)USB-C PD Charging Port

®

Type-C to HDMI/USB-A/RJ45/Type-C Female(PD&Data)

with DP1.4 Alt mode

User Manual

Y10A307-B1

Congratulations

Thank you for purchasing this premium Rocstor product. For optimum performance and

safety, please read these instructions carefully before connecting, operating or using this

product. Please keep this manual for future reference.
