Description

The UEX3D-WP-EU is a USB Device solution utilises HDBaseT™

technology to allow for remote connectivity to a USB 3.2 Gen1 Host

at distances of up to 100m over a single CAT6A cable in a dual EU /

UK wall plate format.

The UEX3D-WP-EU allows for 4 x USB Devices (2 x USB type A,

and 2 x USB-C) to be connected to a compatible Blustream USB

HDBaseT Receiver (Host) extender with support for a combined

transmission data bandwidth of up to 5Gbps.

The UEX3D-WP-EU is backwards compatible with USB 2.0 and 1.1

devices, and utilises bi-directional Power over Cable (PoC) to power

from either end of the HDBaseT link. The UEX3D-WP-EU is ideal

for applications requiring extension of USB 3.2 Gen1 conferencing

cameras, video capture devices, ash/hard drives, KVM devices,

audio devices and other USB 3.2 Gen1 devices.

* Requires compatible Blustream USB 3.2 HDBaseT Host product

UEX3D-WP-EU

136mm

USB 3.2 Gen1 HDBaseT™ Extender - Device

Blustream cannot be held responsible for errors in typography or photography. Specications are subject to change without notice.

86mm

Key Features

•

USB 3.2 Gen1 HDBaseT Extender supporting 2 x USB-C and 2 x

USB-B ports for connection to USB devices

• Supports USB 3.2 signal extension up to 100m over HDBaseT *

• Backwards compatible with USB 2.0 & 1.1 devices

• Combined USB3.2 Gen1 data transfer rate up to 5Gbps *

• Provides up to 3A combined power to USB devices (up to 1.7A per

single USB port)

• Congurable USB device power management via API commands

• Bi-directional PoC (Power over Cable) to power extenders from

either the host or device unit (supports 12-48V PoC)

• Supports bi-directional RS-232 when used with compatible

HDBaseT™ products

• PoC function can be enabled/disabled via dipswitch

• Simple plug and play, no driver installation or setup required

* Signal distribution bandwidth and distance are subject to length of device and

host USB cables, and CAT cable type. It is recommended to use a minimum of

CAT6A cabling.

Compatible with Blustream UEX3H and UEX3H-WP

Please note: This USB HDBaseT Extender product is not compatible with ‘DP Alt

Mode’ signals
