Features

USB Type-C Male (Connect to host computer)

• Supports PD Alt mode

Note:To get max bandwidth, the host computer should support DP1.2 Alt mode.

VGA

• Supports VGA resolution up to

1920x1200@60Hz

• Supports RGB 4:4:4/ YCbCr 4:2:2/ YCbCr

4:2:0

• Supports HDCP1.4&2.2

Introduction

Package Contents

This is a premium Rocstor Type-C to DVI，HDMI and VGA Adapter. It allows you to

transmit signals from a Type-C source to a high denition DVI or HDMI or VGA display

(TV sets, projectors, etc). It can work on all DP Alt mode supported Type-C host.

With this product, you can watch videos or slideshows together on the big screen.

HDMI

• Supports HDMI resolution up to

4Kx2K@60Hz

• Supports HDMI 8/10/12bit

• Supports HDR

• Supports HDMI 9 Gbps Bandwidth

DVI

• Supports DVI Resolution up to

1080P@60Hz

Upstream:

Downstream:

FEATURES

• Allows HDMI and VGA to output simultaneously with 1080P/60Hz under SST mode

• Allows DVI and VGA to output simultaneously with 1080P/60Hz under SST mode

• HDMI and DVI can not work at the same time

• Priority: VGA>DVI>HDMI

Before attempting to use this unit, please check the packaging and make sure

the following items are contained in the Packaging:

• Main unit x1

• User Manual x1

Specication

How to Use

System Requirement

Input / Output Connector

Input

Output

DVI Female x1

HDMI Female x1

VGA Female x1

USB Type-C Male x1

Warranty

Limited Warranty3 Year

Environmental

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

Regulatory Approvals

CerticationsFCC, CE

Mechanical

Size (L-W-H)

Weight (Net) 39.5g - (0.08 Lbs)

85x45x14.5mm - 3.3”x 1.7”x 0.5”

Accessories

User ManualEnglish Version

1 - Connect the USB-C male port of this multiport adapter to the host computer.

2 Connect the DVI port of this multiport adapter to a DVI monitor.-

3 - Connect the HDMI port of this multiport adapter to an HDMI monitor.

4 - Connect the VGA port of this multiport adapter to a VGA monitor.

0°C to + 45°C - (32°F to + 113°F)

10% to 90 % RH (no condensation)

-10°C to + 70°C - (14°F to + 158°F)

10% to 90 % RH (no condensation)

®

Y10A250-A1

Congratulations

Thank you for purchasing this premium Rocstor this product. For optimum performance

and safety, please read these instructions carefully before connecting, operating or using

this product. Please keep this manual for future reference.

Host computer with an available USB-C Port

- USB 3.0/3.1/3.2

Operating systems

- Windows 7 / 8 / 10 / 11

- Android OS

- Chrome OS

- Linux OS

- Mac OS v10.5 or above

USB Type-C® Multiport Video Adapter- 3-in-1

HDMI® 4K@60Hz, VGA, DVI®

User Manual
