PowerWalker VFI 2000 ICR IoT Handleiding
Pagina's 6 UPS
Bekijk de handleiding van PowerWalker VFI 2000 ICR IoT gratis online of download de PDF. 13 mensen vonden deze handleiding nuttig. Vraag over dit model? Stel een vraag
1
ENGLISH
General Manual
PowerWalker Uninterruptible Power Supply
This manual contains important safety precautions, general UPS instructions and useful hints that should
be followed during installation, operation and maintenance of the UPS and batteries. Before using the
product, please also read the second manual that covers series-specific information.
I.Safety & Emergency
1.This is a product for commercial and industrial application (Class A). Installation restrictions or
additional measures may be needed to prevent potential disturbances.
2.Do not allow liquids or any foreign object to enter the UPS. No containers with liquids shall be placed
on the UPS or in close vicinity.
3.The utility power outlet shall be near the equipment and easily accessible. In the event of an
emergency, press OFF button and disconnect the power cord from the AC power supply.
4.In the event of fire in the vicinity, please use dry powder fire extinguishers.
5.Even after the unit is disconnected from the input socket, internal components are still connected to
the battery which is potentially dangerous. If any internal inspection or replacement of the battery is
required, please contact a qualified technician.
6.Please recycle all possible components. The batteries are not to be disposed in your domestic waste
container.
7.Installation and usage must be performed in accordance with the local electric regulations and safety
requirements. Please check if protected equipment or environment has any special requirements.
II.Information
1.Uninterruptible Power Supplies are designed to protect sensitive electronic equipment from power
outages and interference. It is equipped with many features that allow any attached equipment to
operate longer and with higher reliability.
2.The product is pluggable to the wall socket and if your version is delivered with batteries already
installed, it can be operated by laymen.
3.Icon Φ on the rating label stands for phase symbol.
4.This product complies with the safety and environmental regulations in EU.
III.Preparation
1.This unit is intended for installation in a controlled environment. Operating under following
conditions is prohibited:
Combustible gas, corrosive substance or heavy dust.
Extraordinarily high or low temperature.
Standing or running water or extreme humidity.
Exposed to direct sunshine or near any heating apparatus.
Serious vibrations.
Product specificaties
| Merk: | PowerWalker |
| Categorie: | UPS |
| Model: | VFI 2000 ICR IoT |
| Kleur van het product: | Zwart |
| Gewicht: | 23300 g |
| Breedte: | 438 mm |
| Diepte: | 600 mm |
| Hoogte: | 86 mm |
| Geluidsniveau: | 50 dB |
| Gewicht verpakking: | 27300 g |
| Breedte verpakking: | 580 mm |
| Diepte verpakking: | 780 mm |
| Hoogte verpakking: | 240 mm |
| Gebruikershandleiding: | Ja |
| Internationale veiligheidscode (IP): | IP20 |
| LED-indicatoren: | Ja |
| Vormfactor: | Rackmontage/toren |
| USB-poort: | Ja |
| Meegeleverde kabels: | Input power cable, Output power cable, USB cable |
| Ingebouwde ventilator: | Ja |
| Accu/Batterij voltage: | 12 V |
| Aantal USB 2.0-poorten: | 1 |
| Soort serieële aansluiting: | RS-232 |
| Ondersteund aantal accu's/batterijen: | 6 |
| RS-232 port: | 1 |
| Uitgangsvermogen: | 2000 W |
| Batterij capaciteit: | 7 Ah |
| Accu/Batterij oplaadtijd: | 3 uur |
| ECO mode: | Ja |
| Frequentie: | 40/70 Hz |
| Type koeling: | Actief |
| Stekker: | C20 stekker |
| Efficientie: | 93 procent |
| Rackcapaciteit: | 2U |
| Bedrijfstemperatuur (T-T): | 0 - 45 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 0 - 95 procent |
| Type beeldscherm: | LCD |
| Aantal AC uitgangen: | 8 AC-uitgang(en) |
| Stopcontacttypes: | C13 stekker |
| Output power capacity: | 2 kVA |
| Ingang operation voltage (min): | 160 V |
| Ingang operation voltage (max): | 300 V |
| Uitgang operation voltage (min): | 200 V |
| Uitgang operation voltage (max): | 240 V |
| Crest factor: | 3:1 |
| UPS-topologie: | Dubbele conversie (online) |
| Aantal input fases: | 1 |
| Seriële interface: | Ja |
| Emergency Power Off (EPO): | Ja |
| Output voltage THD: | 1 procent |
| Aantal output fases: | 1 |
| Golfvorm: | Zuivere sinus |
| Input stroom THD: | 5 procent |
| Noodstop-aansluiting (EPO): | Ja |
| Output vermogensfactor: | 1 |
| Laadstroom: | 1.5 A |
