User’s Manual of IGS Series

Industrial Layer 2+

Rack-mount Managed

Ethernet Switch

IGS-5225-16T4S

IGSW-24040T

User’s Manual of IGS-5225-16T4S/IGSW-24040T

Trademarks

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no

warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for

a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability

for any inaccuracies or omissions that may have occurred.

Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of

PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes

no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to

this User's Manual and/or to the products described in this User's Manual, at any time without notice.

If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and

suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

CE Mark Warning

This device is compliant with Class A of CISPR 32. In a resdential environment this equipment may cause radio interference.

Energy Saving Note of the Device

This power required device does not support Standby mode operation. For energy saving, please remove the power cable to

disconnect the device from the power circuit. In view of saving the energy and reducing the unnecessary power consumption, it

is strongly suggested to remove the power connection for the device if this device is not intended to be active.

WEEE Warning

To avoid the potential effects on the environment and human health as a result of the presence of hazardous

substances in electrical and electronic equipment, end users of electrical and electronic equipment should

understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted

municipal waste and have to collect such WEEE separately.

Revision

User's Manual of PLANET Industrial L2+ Rack-mount Managed Ethernet Switch

FOR MODELS: IGS-5225-16T4S(V2) / IGSW-24040T(V4)

REVISION:4.0 (November, 2022)

Part No: EM-IGS-5225-16T4Sv2_IGSW-24040Tv4_v1.0

Product specificaties

Merk:	Planet
Categorie:	Schakelaar
Model:	IGS-5225-16T4S
Kleur van het product:	Blauw
Gewicht:	2672 g
Breedte:	440 mm
Diepte:	200 mm
Hoogte:	44.5 mm
Materiaal behuizing:	Metaal
Internationale veiligheidscode (IP):	IP30
LED-indicatoren:	Ja
Stroom:	0.4 A
Vormfactor:	1U
Vermogensverbruik (max):	15.2 W
DC voltage input:	36 - 60 V
Certificering:	FCC Part 15 Class A, CE
Netwerkstandaard:	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ondersteunde beveiligingsalgoritmen:	SNMPv3, SSH, SSL/TLS
Temperatuur bij opslag:	-40 - 85 °C
Web-gebaseerd management:	Ja
Luchtvochtigheid bij opslag:	5 - 95 procent
Reset button:	Ja
Rack-montage:	Ja
Redundante voeding:	Ja
Quality of Service (QoS):	Ja
VLAN=ondersteuning:	Ja
Auto MDI/MDI-X:	Ja
Virtuele LAN-functies:	Private VLAN, Tagged VLAN, Protocol-based VLAN
Access Control List (ACL):	Ja
Power over Ethernet (PoE):	Nee
Switchingcapaciteit:	40 Gbit/s
MAC-adrestabel:	8000 entries
10G support:	Nee
Datastroombeheer:	Ja
Rate limiting:	Ja
IGMP snooping:	Ja
Switch type:	Managed
Multicast-ondersteuning:	Ja
Aantal basis-switching RJ-45 Ethernet-poorten:	16
Aantal Gigabit Ethernet (koper)-poorten:	16
Console port:	RJ-45
Switch-laag:	L2+
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF:	4
Throughput:	29.76 Mpps
Jumbo Frames ondersteuning:	Ja
Port mirroring:	Ja
Spanning tree protocol:	Ja
Verbindingsaggregatie:	Ja
Full duplex:	Ja
Koperen ethernetbekabelingstechnologie:	10BASE-T, 100BASE-T, 1000BASE-T
SSH/SSL support:	Ja
Warmtedissipatie:	51.8 BTU/h
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Bedrijfstemperatuur (T-T):	-10 - 60 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 95 procent
Code geharmoniseerd systeem (HS):	85176990
Jumbo frames:	9000
Broadcast stormbeheer:	Ja
Store-and-forward:	Ja
System event log:	Ja
MAC-adres zelfverouderende functie:	Ja
MAC-adres zelflerende functie:	Ja
IP-MAC-Port binding:	Ja
ARP-inspectie:	Ja
Traffic-classificatie:	Ja
BPDU filtering / bescherming:	Ja
Authenticatie:	Guest VLAN, MAC-based authentication, Port-based authentication
