User’s Manual of MGSW-24160F

User’s Manual

MGSW-24160F

16-Port 100/1000Base-X SFP

+ 8-Port 10/100/1000Base-T

L2/L4 Managed Metro Ethernet Switch

User’s Manual of MGSW-24160F

Trademarks

Contents subject to which revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no

warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for

a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability

for any inaccuracies or omissions that may have occurred.

Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of

PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes

no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to

this User's Manual and/or to the products described in this User's Manual, at any time without notice.

If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and

suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at whose own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be

required to take adequate measures.

Energy Saving Note of the Device

This power required device does not support Standby mode operation.

For energy saving, please remove the power cable to disconnect the device from the power circuit.

Without removing power cable, the device is will still consuming power from the power source. In the view of Saving the Energy

and reduce the unnecessary power consuming, it is strongly suggested to remove the power connection for the device if this

device is not intended to be active.

WEEE Warning

To avoid the potential effects on the environment and human health as a result of the presence of hazardous

substances in electrical and electronic equipment, end users of electrical and electronic equipment should

understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted

municipal waste and have to collect such WEEE separately.

Revision

PLANET 16-Port 100/1000Base-X SFP + 8-Port 10/100/1000Base-T L2/L4 Managed Metro Ethernet Switch

User's Manual

FOR MODEL: MGSW-24160F

REVISION: 1.1 (May. 2012)

Part No: EM-MGSW-24160F (2080-A93270-000)

Product specificaties

Merk:	Planet
Categorie:	Schakelaar
Model:	MGSW-24160F
Kleur van het product:	Blauw
Gewicht:	3000 g
Breedte:	440 mm
Diepte:	200 mm
Hoogte:	44.5 mm
LED-indicatoren:	Ja
Aan/uitschakelaar:	Ja
Vormfactor:	1U
Meegeleverde kabels:	RS-232
Compatibele geheugenkaarten:	Niet ondersteund
Snelstartgids:	Ja
Inclusief AC-adapter:	Ja
Vermogensverbruik (max):	38 W
Netwerkstandaard:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ondersteunde beveiligingsalgoritmen:	SNMP, SSH, SSL/TLS
Temperatuur bij opslag:	-10 - 70 °C
Aantal ventilatoren:	2 ventilator(en)
Web-gebaseerd management:	Ja
Luchtvochtigheid bij opslag:	5 - 95 procent
Reset button:	Ja
Rack-montage:	Ja
MAC adres filtering:	Ja
Vermogenstoevoer inclusief:	Nee
Quality of Service (QoS):	Ja
VLAN=ondersteuning:	Ja
Auto MDI/MDI-X:	Ja
Virtuele LAN-functies:	Private VLAN, Protocol-based VLAN, Port-based VLAN
Access Control List (ACL):	Ja
Power over Ethernet (PoE):	Ja
Stapelbaar:	Ja
Switchingcapaciteit:	48 Gbit/s
MAC-adrestabel:	16000 entries
10G support:	Nee
Datastroombeheer:	Ja
IGMP snooping:	Ja
Switch type:	Managed
Multicast-ondersteuning:	Ja
Aantal basis-switching RJ-45 Ethernet-poorten:	8
Console port:	RS-232
Switch-laag:	L2+
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF:	16
Throughput:	35.6 Mpps
Jumbo Frames ondersteuning:	Ja
Port mirroring:	Ja
Spanning tree protocol:	Ja
Verbindingsaggregatie:	Ja
Full duplex:	Ja
Koperen ethernetbekabelingstechnologie:	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
DHCP-functies:	DHCP server, DHCP client
SSH/SSL support:	Ja
Rubberen voetjes:	Ja
IP routing:	Ja
Auto-negotiation:	Ja
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Bedrijfstemperatuur (T-T):	0 - 60 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 95 procent
Code geharmoniseerd systeem (HS):	85176990
Aantal Power over Ethernet plus (PoE +)-poorten:	8
Jumbo frames:	10000
Hoeveelheid Power over Ethernet (PoE) ports:	8
Bescherming lus:	Ja
Store-and-forward:	Ja
Klemmenblok inclusief:	Ja
System event log:	Ja
Rekbevestigingspakket:	Ja
Fiber ethernet cabling technologie:	1000BASE-X
MAC-adres zelfverouderende functie:	Ja
MAC-adres zelflerende functie:	Ja
Klemmenblokpoort:	Ja
IP-MAC-Port binding:	Ja
Transmissie afstand (max):	120 km
Aantal wachtrijen:	8
ARP-inspectie:	Ja
Aantal trunks:	24
Traffic-classificatie:	Ja
BPDU filtering / bescherming:	Ja
Aantal gefilterde multicast-groepen:	255
Fiber type:	Multimode
Traffic shaping:	Ja
Auto-edge-port:	Ja
Admin-edge-port:	Ja
