Pagina 1/24
ENGLISH
FRANÇAIS
DEUTSCH
ENGLISH
日本語
DPQX1648YA/X1
Thank you for purchasing this Panasonic product.
■ To customers
The “Installation Instructions” is intended for use by installation personnel. Be sure to employ certified
personnel to perform the installation.
After installation, have the installation personnel return these “Installation Instructions” to you, and save it for future use.
When moving or removing the projector, give this manual to the certified personnel and have them perform the
procedure.
■ To installation personnel
Read the “Installation Instructions” thoroughly and then perform the operation correctly and safely.
Be sure to read through the section entitled “Read this first!” (page 3) before proceeding with the installation.
After installation, return these “Installation Instructions” to the customer.
* The figure above shows this product combined with the separately sold ET-PKD520H Ceiling Mount Bracket (for High
Ceilings).
Installation Instructions
Projector Mount Bracket
Model No. ET-PKD521B
2 -
ENGLISH
Contents
Read this rst! ................................................................................................... 3
Product components ......................................................................................... 4
Standard installation dimensions .................................................................... 5
<When using a lens other than the ET-D3LEW200 Zoom lens, the ET-D3LEU100 /
ET-D75LE95 / ET-D75LE90 Fixed-focus lens, or ET-D3LEF70 Fisheye lens> .......................... 5
<When using the ET-D3LEU100 Fixed-focus lens / ET-D3LEW200 Zoom lens> .................... 12
<When using the ET-D75LE95 / ET-D75LE90 Fixed-focus lens> .................................... 15
<When using the ET-D3LEF70 Fisheye lens> ......................................................................... 18
Installation ........................................................................................................ 21
Setting up the screen ........................................................................................................ 21
Screws tightening torques ................................................................................................ 21
Installing the bracket to the projector ................................................................................ 21
Attaching the wire rope to the projector ............................................................................ 22
Specications .................................................................................................. 23
