44
CY-VHD9500U
CY-VHD9500U
45
E
N
G
L
I
S
H
1
E
N
G
L
I
S
H
2
Safety Information.............................................................................Page 2
Notes on Use.........................................................................................10
Installation Guide....................................................................................12
Features...............................................................................................13
System Upgrade.................................................................................... 14
Discs/Cards that can be Played Back.............................................................15
Accessories.......................................................................................... 44
Name of Controls....................................................................................46
Monitor Position Adjustment.......................................................................50
Remote Control Unit Preparation..................................................................51
IR Wireless Headphones Preparation........................................................... 52
General................................................................................................54
Playing Discs (Disc General/DVD video/Video CD).............................................56
Playing Discs (DVD video/Video CD).............................................................58
Playing Discs (CD/MP3)............................................................................60
VTR (Game etc.).....................................................................................64
Playing SD Cards....................................................................................66
Display (SCREEN) Settings.........................................................................76
Other (USER) Settings..............................................................................78
DVD video Settings..................................................................................80
Aspect Ratio..........................................................................................84
Replacing the Bulb of the Dome Light............................................................85
Troubleshooting......................................................................................86
Notes on Discs/Cards...............................................................................94
Language Code List.................................................................................96
Defi nition of Terms..................................................................................97
After-sales Service for Products...................................................................98
Specifi cations......................................................................................100
Accessories
Contents
ItemDiagramQ’ty
Paper Template
(YEFM991521)
1
Under Cover
(YEFX9995134)
1
Slide Plate (upper)
(YEFG013018)
1
Slide Plate (lower)
(YEFG013017)
1
Base Plate
(YEFG013016)
1
Space Washer (A)
(YEFL02806)
6
Space Washer (B)
(YEFL02807)
6
Space Washer (C)
(YEFL02808)
6
Space Washer (D)
(YEFL02809)
6
Screw (YEJS03250)
12
Screw (YEJS05100)
6
Screw (YEFJ05101)
6
Nuts (YEJN01122)
12
Push Nuts (YEJN03100)
6
Spring Washer (XWA5BFZ)
6
Flat Washer (XWE5E10FZ)
6
Screw (for resin)
(XTB3+10GFX)
6
Cord Clamp
(SHR4C102)
2
Magic tape (“Velcro”)
(YFS014C089ZA)
(YFS014C090ZA)
1 pair
Wiping Cloth
(YEFX9991793)
1
Note:
≥The number in parenthesis underneath each
accessory part name is the part number for
maintenance and service.
≥Accessories and their parts numbers are subject
to modifi cation without prior notice due to
improvements.
ItemDiagramQ’ty
Remote Control Unit
(YEFX9995179)
1
IR Wireless Headphones
(YEFX9992629)
2
Lithium Battery for
Remote Control Unit
<CR2025/1F>
1
Batteries for IR Wireless
Headphones
<R03, AAA, UM-4>
4
Instruction Kit
≥ Operating Instructions
(YEFM284227)
1
≥ Installation
Instructions
(YEFM293246)
1
≥ Warranty Card, etc.
1 set
Power Connector
(Main unit side)
(YAJ024C100ZA)
1
Power Connector
(Vehicle side)
(YAJ024C104ZA)
1
This indicates an operation
which can be performed using
the main unit only.
This indicates an operation
which can be performed using
the remote control unit only.
