FOR YOUR SAFETY

WARNING: BE SURE THE ELECTRICITY TO THE WIRES

YOU ARE WORKING ON IS SHUT OFF; EITHER THE FUSE IS

REMOVED OR THE CIRCUIT BREAKER IS SHUT OFF.

GENERAL

You don’t need special tools to install this xture. Be sure to follow

the steps in the order given. Under no circumstances should

a xture be hung on house electrical wires, nor should a swag

type xture be installed on a ceiling which contains a radiant type

heating system. Read instructions carefully. If you are unclear as

to how to proceed, consult a qualied electrician.

NOTE: Proper wiring is essential for the safe operation of this

xture.

FIXTURE ASSEMBLY

Carefully remove the xture from the carton and check that all

parts are included as shown in gure. Be careful not to misplace

any of the screws or parts, which are needed to install this xture.

INSTALLATION

IMPORTANT: Do not attach xture directly to outlet box.

Dimmable with ELV and/or LED compatible wall dimmer

switches.

STEP 1: Attach the glass (F) into the xture holder (G). Use a

screwdriver to tighten screws (H), see Figure 1.

STEP 2: Secure mounting plate (B) to outlet box (A) using junction

boxes screws (C) (size: 8/32, 1/2"L). The side of the mounting back

plate marked “GND” must face out.

GROUNDING INSTRUCTIONS

STEP 1: Connect the electrical wires as shown in Figure 2, making

sure that all wire connectors are secured. If your outlet has a

ground wire (green or bare copper), connect the xtures ground

wire to it. Otherwise, connect the xture ground wire directly to the

mounting plate (B) using the green screw provided. After wires are

connected, tuck them carefully inside the outlet box.

NEVER CONNECT GROUND WIRE TO BLACK OR WHITE

POWER SUPPLY WIRES.

FINAL ASSEMBLY

STEP 1: Align the xture back plate (E) over the mounting plate (B)

and secure with screws (D).

CLEANING

To clean, wipe xture with a soft cloth. Clean glass with a mild

soap. Do not use abrasive materials such as scouring pads or

powders, steel wool or abrasive paper.

ORDERING PARTS

Keep this sheet for future reference, and in case you need to order

replacement parts. Be sure to use exact wording from illustration

when ordering parts.

Line art shown may not exactly match the xture enclosed. However, the installations

do apply to this xture.

La ilustración puede no concordar exactamente con la pieza enviada. Sin embargo,

las instalaciones sí aplican para esta pieza.

Les images peuvent ne pas correspondre exactement au luminaire de la boîte.

Par contre, les directives d’installation s’appliquent au luminaire.

INSTALLATION AND SAFETY INSTRUCTIONS

ITEM NO: 62-1501, 62-1502, 62-1511, 62-1512

ARTÍCULO Nº: 62-1501, 62-1502, 62-1511, 62-1512

ARTICLE N°: 62-1501, 62-1502, 62-1511, 62-1512

FIXTURE

WIRES

Black or

Smthoo

HOUSE

WIRES

Black

(Hot)

FIXTURE

WIRES

White or

Riedbb

HOUSE

WIRES

White

(Neutral)

FIXTURE

WIRES

Bare

Coerpp

(Gro)und

HOUSE

WIRES

Grnoree

Bare

Copper

(Ground)

FIGURE 1.

FIGURE 2.

STEP 1

STEP 2
