ENGLISH

UNITED KINGDOM • CUSTOMER SERVICE

Internet: www.clasohlson.co.uk

1

2

3

Ver. 20210512

Fabric Pendant Light

Art.no 36-8178 Model OCL-0970P 280-FWH1

Please read the entire instruction manual before using the product

and then save it for future reference. We reserve the right for any

errors in text or images and any necessary changes made to

technical data. In the event of technical problems or other queries,

please contact our Customer Services.

Class ll luminaire.

Lamp plug sold separately.

Safety

• The product must only be connected to a 230V AC, 50Hz

power supply.

• Never use the product if it or the mains lead is damaged in any way.

Care and maintenance

• Carefully dust/vacuum clean the light fitting whenever required.

Responsible disposal

This symbol indicates that the product should not be

disposed of with general household waste. This applies

throughout the entire EU. In order to prevent any harm

to the environment or health hazards caused by incor-

rect waste disposal, the product must be handed in for

recycling so that the material can be disposed of in a

responsible manner. When recycling your product, take it to your

local collection facility or contact the place of purchase. They will

ensure that the product is disposed of in an environmentally sound

manner.

Specifications

Rated voltage220–240V AC, 50/60Hz

Diameter28 cm

Lamp holderE27, max 46W

Mains lead 1.5m

This product is only designed for indoor use.

Assembly

1

2

3

Installation

Note: Always disconnect thepower to thecircuit

you are working on by unscrewing thefuse or

switching thecircuit breaker off depending on

thetype of breaker system you have in your

consumerunit.

1. Loosen theceiling cup’s

strain relief screw (1) so that

thelead moves freely.

2. Remove theterminal

block (3), if necessary,

from thehanging loop

(2) in order to connect

theincoming neutral wire

(blue) to theterminal block

terminal marked “N”.

Connect theincoming live

wire (usually brown) to

theterminal marked “L”.

Note: InScandinavia you are

allowed to connect aclass ll

(non-earthed ) plug (sold separately) to this lamp fitting.

3. Refit any removed terminal block back onto theplastic plate

and adjust thelead to thedesired length by threading it

through thehangingloop.

4. Hook thehanging loop onto aceiling bracket/hook.

5. Push theceiling cup flush against theceiling and tighten

thestrain relief screw securely.

6. If you should need to shorten thelead by cutting it, make sure

that it is disconnected from themains power supply. Attach

thesupplied cable tie 3 cm under thepoint where thelead is

to be cut in order to prevent thefabric from fraying.

7. Screw thelight bulb (sold separately) into thesocket of

thelamp holder.

8. Turn thepoweron.
