PRODUCT DATA
NSR-9514B
Designed in USA, manufactured in China at a ISO-9001 certi ed Bayco facility.PDS_NSR-9514B_141216_A
Bayco Products, Inc. • 640 S. Sanden Blvd • Wylie, TX 75098 • 800.233.2155 • www.mynightstick.com
Polymer Multi-Function Duty / Personal-Size Flashlight
Rechargeable
MARKET APPLICATIONS
Law enforcement, re & rescue, industrial, security, hardware/tool, automotive, hunting/recreation.
DESCRIPTION
The NSR-9514B rechargeable glass- lled nylon polymer LED ashlight, o ers 3 microprocessor-controlled brightness
modes as well as a strobe function. Utilizing a CREE® LED, the 9514B has an impressive runtime of 4.25 hours in full-
brightness mode. The 350 lumen output in combination with the high e ciency deep parabolic re ector design
throws a usable beam of light 313 meters…that’s over 1,026 feet. The 9514B has a two button design, a switch located
on the waterproof body of the light and one in the tail cap. Both switches operate in tandem with one another. Meets
requirements of NFPA-1971-8.6 (2013).
CASE MATERIAL
Glass- lled Nylon Polymer w/ Aircraft-grade 6061-T6 Aluminum Tail Cap & Bezel both with a Type III Hard Anodized
Finish - Black
DIMENSIONS
Length: 8.9 inches (226 mm) • Handle diameter 1.2 inches (30 mm) • Head diameter 1.6 inches (41 mm)
WEIGHT
Weight: 10.1 oz. (286 g) with battery installed.
LENS
Unbreakable polycarbonate with scratch resistant coating.
LIGHT SOURCE
Cree® LED. Impervious to shock with a 50,000 + hour lifetime.
LIGHT OUTPUT
High-Brightness - 350 lumens • Medium-Brightness - 200 lumens • Low-Brightness 55 lumens • Strobe - 300 lumens
ON/OFF
Single Body Switch & Single Tail Switch (Tandom Functionality) - Momentary or Constant-on Flashlight, High, Medium
and Low-Brightness Flashlight, Strobe
RUN-TIME
High-brightness - 4.25 hours • Medium-brightness - 8.5 hours • Low-brightness - 32.5 hours • Strobe - 5.5 hours
BATTERY
2-cell, 3.7 Volt Lithium-ion battery pack.
CHARGING
Charging platform is wall or vehicle mountable. Charges in 4 hours (typical) on 100 / 240 50/60 Hz or 12V DC.
FEATURES
• CREE® LED technology – 50,000 + hours LED life
• Momentary or constant-on plus 3 brightness levels & strobe
• Sharp focused beam
• Glass- lled nylon polymer housing
• Aircraft-grade 6061-T6 aluminum tail-cap and bezel both with a Type III hard anodized nish
• Non-slip grip
• Body & tail switch
• Waterproof
• Impact & chemical resistant
• Meets requirements of NFPA-1971-8.6 (2013)
• Serialized for personal identi cation
• Powered by rechargeable Lithium-ion battery (included)
• Includes wall or vehicle mounted charger as well as AC and DC power supply and anti-roll ring
WARRANTY
Limited Lifetime Warranty • Includes the LEDs, housing and lenses. Rechargeable batteries, chargers, switches,
electronics and included accessories are warranted for a period of two years with proof of purchase. Disposable, non-
rechargeable batteries are excluded from this warranty. Normal wear and failures which are caused by accidents,
misuse, abuse, faulty installation and lightning damage are also excluded.
OPTIONAL ACCESSORIES
5 Bank Charger,
Direct Wire Kit, USB
Charging Cable,
Red, Yellow & Blue
Safety Cones
2m
8h 30min
200
235m
12075cd
4h 15min
350
313m
24100cd
MEDIUM
32h 30min
55
118m
6200cd
LOWHIGH
1m
APPROVALS
Product specificaties
| Merk: | NightStick |
| Categorie: | Lamp |
| Model: | NSR-9514 |
