Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com

INS-T500-24

Instruction Manual

TAC-500/510/550

US PATENT 9,713,217

WARNINGS

yLithium-ion batteries must be used and charged properly. Improper use can result in serious

injury, re, or death.

yNOT FOR USE IN HAZARDOUS LOCATIONS. Do not use this product in explosive

atmospheres, near ammable liquids, or where explosion proof or intrinsically safe lighting

is required.

yDO NOT use this product in the proximity of vehicles or equipment when there is a risk of

ammable liquids coming into contact with the ashlight.

yLight can become hot while on. To prevent damage DO NOT cover or place next to any

potentially ammable materials while in use.

yDo not leave the battery in direct sunlight or use or store the battery inside cars in hot weather.

yDo not expose the battery to water or salt water, or allow the battery to get wet.

yDo not store the battery with metallic objects that may cause a short circuit.

yImmediately discontinue use of the battery if the battery emits an unusual smell, feels hot,

changes color, changes shape or appears abnormal in any way.

yKeep out of the reach of children.

INITIAL USE

Fully charge the TAC before the rst use, or if the battery is new or has been unused for

several months. The maximum charge time required is approximately 4 hours.

DAILY USE

yUse only the supplied Nightstick charger, battery and AC or DC adapter. For best

performance, charge the TAC when the ashlight beam starts to dim.

yConnect the AC power adapter to the charger. The LED indicator will not be illuminated at

this point.

yWith the ashlight facing forward, slide the TAC into the charger until the contacts snap into place.

yThe LED indicator changes to constant red indicating the TAC is properly inserted into the

charger and is in fact charging. The LED indicator remains red until the battery is fully charged.

At full charge, the LED indicator turns green.

yThe total time to full charge the TAC varies depending on the remaining charge in the

battery pack.

yTo conrm a full charge, keep the TAC in the charger and turn it on. The LED indicator will

change to red. Turn off the TAC. If the TAC is fully charged, the LED indicator will turn green.

If not, it remains red until the charge is completed and the LED indicator turns green. The TAC

will now be fully charged.

OPERATION

The TAC has ve light modes: momentary ashlight, full brightness ashlight, medium

brightness ashlight, low brightness ashlight and strobe. The TAC has a single tail switch

providing access to all modes.

MOMENTARY FLASHLIGHT MODE

Lightly press the tail switch for momentary operation. Release the switch to turn the light off.

CONSTANT-ON

Press the tail switch until it clicks and then release for constant-on in high-brightness mode.

Press and release the tail switch again to turn the light off.

SELECT BRIGHTNESS LEVEL

Press and hold down the tail switch. The light will cycle from high to medium to low and

then back up again at a rate of approximately one mode per second. The light will continue to

cycle up and down through the various modes as long as the tail switch is held down. When the

desired brightness level is reached, simply release the tail switch, and the light will remain in that

brightness mode. Pressing and holding the tail switch again will cause the light to cycle from

whatever mode it is currently in. Press and release the tail switch to turn the light off.

STROBE FUNCTION

To activate the strobe, rapidly double click the tail switch. The strobe can be activated from

any mode including off. Press and release the body switch to turn the strobe off.

Strobe Warning

Exposure to strobing lights may cause dizziness, disorientation, and nausea. A very small

percentage of people suffer from photosensitive epilepsy and may experience seizures or

blackouts triggered by strobing lights. For more information from the EPILEPSY FOUNDATION

about photosensitivity and seizures, please visit www.epilepsy.com. Anyone who has had

symptoms linked to this condition should consult a doctor before using this product.

CR-123 BATTERY CARRIER

The CR123 battery carrier converts the

TAC from rechargeable Lithium-ion to non-

rechargeable Lithium battery operation.

Load two CR-123 Lithium batteries with

the positive terminals pointing in the direction

of the arrow.

NOTE: The ashlight cannot be charged

with the CR-123 CARRIER installed.

LIMITED LIFETIME WARRANTY

Bayco Products, Inc. warrants this product to be free from defects in workmanship and

materials for the original purchaser’s lifetime. The Limited Lifetime Warranty includes the LEDs,

housing and lenses. Rechargeable batteries, chargers, switches, electronics and included

accessories are warranted for a period of two years with proof of purchase. Normal wear and

failures which are caused by accidents, misuse, abuse, faulty installation and lightning damage

are excluded.

We will repair or replace this product should we determine it to be defective. This is the

only warranty, expressed or implied, including any warranty of merchantability or tness for a

particular purpose.

For a complete copy of the warranty, go to www.baycoproducts.com/bayco-product-support/

warranties. Retain your receipt for proof of purchase.

Mode d’emploi

TAC-500/510/550

AVERTISSEMENTS

yLes batteries au lithium-ion doivent être utilisées et rechargées correctement. Une mauvaise

utilisation peut causer des blessures graves, un incendie ou la mort.

yNE PAS UTILISER DANS DES ENDROITS DANGEREUX. Ne pas utiliser ce produit dans

des atmosphères explosibles, à proximité de liquides inammables, ou un endroit antidéagrant

ou un emplacement dont un éclairage à sécurité intrinsèque est requis.

yNE PAS utiliser ce produit à proximité de véhicules ou équipements quand il y a risque de

liquides inammables entrant en contact avec la lampe de poche.

yLa lumière peut être chaude lorsqu’elle est allumée. Pour éviter tout dommage NE PAS

couvrir ou placer à proximité de matériaux potentiellement inammables pendant qu’elle est

allumée.

yNe pas laisser la batterie en contact direct avec les rayons de soleil ou utiliser ou conserver

la batterie à l’intérieur des autos lorsqu’il fait chaud.

yNe pas mettre la batterie dans l’eau ou l’eau salée. La batterie ne doit jamais être mouillée.

yNe pas conserver la batterie avec des objets métalliques qui peuvent causer un court-circuit.

yNe pas mettre la batterie dans l’eau ou l’eau salée. La batterie ne doit jamais être mouillée.

yNe pas conserver la batterie avec des objets métalliques qui peuvent causer un court-circuit.

yCesser immédiatement d’utiliser la batterie si elle émet une odeur inhabituelle, semble

chaude, change de couleur ou de forme ou paraît anormal.

yGarder hors de la portée des enfants.

UTILISATION INITIALE

Chargez la TAC à bloc avant la première utilisation ou si la batterie est neuve ou n’a pas

été utilisée depuis plusieurs mois. La durée maximale de charge requise est d’environ 4 heures.

Included in the box - Compris dans la boîte - Incluido en la caja
