MUZ-HM24NA
PARTS CATALOG (OBB747)
SERVICE MANUAL
No. OBH747
REVISED EDITION-H
CONTENTS
1. TECHNICAL CHANGES ······························3
2. PART NAMES AND FUNCTIONS ··················3
3. SPECIFICATION ········································4
4. OUTLINES AND DIMENSIONS ·····················9
5. WIRING DIAGRAM ···································11
6. REFRIGERANT SYSTEM DIAGRAM ···········16
7. DATA ······················································20
8. ACTUATOR CONTROL ·····························33
9. SERVICE FUNCTIONS ······························34
10. TROUBLESHOOTING ·······························35
11. DISASSEMBLY INSTRUCTIONS ·················60
OUTDOOR UNIT
OBH747 REVISED EDITION-G is void.
HFC
utilized
R410A
Models
MUZ-HM09NA
-
U1
,
U2
,
U8
MUZ-HM18NA
-
U1
,
U2
MUZ-HM09NA2
-
U1
,
U8
MUZ-HM18NA2
-
U1
MUZ-HM09NAH
-
U1
MUZ-HM18NAH
-
U1
MUZ-HM12NA
-
U1
,
U2
,
U8
MUZ-HM24NA
-
U1
,
U2
MUZ-HM12NA2
-
U1
,
U8
MUZ-HM24NA2
-
U1
MUZ-HM12NAH
-
U1
MUZ-HM24NAH
-
U1
MUZ-HM15NA
-
U1
,
U2
MUZ-HM15NA2
-
U1
MUZ-HM15NAH
-
U1
Indoor unit service manual
MSZ-HM•NA Series (OBH746)
Revision H:
• A warning when opening or closing the
valve has been added.
