Mitsubishi MUZ-HM12NA-U1 Handleiding
Pagina's 66 Warmtepomp
Bekijk de handleiding van Mitsubishi MUZ-HM12NA-U1 gratis online of download de PDF. 9 mensen vonden deze handleiding nuttig. Vraag over dit model? Stel een vraag
Models
MUZ-HM09NA
-
U1
,
U8
MUZ-HM18NA
-
U1
MUZ-HM09NA2
-
U1
,
U8
MUZ-HM18NA2
-
U1
MUZ-HM12NA
-
U1
,
U8
MUZ-HM24NA
-
U1
MUZ-HM12NA2
-
U1
,
U8
MUZ-HM24NA2
-
U1
MUZ-HM15NA
-
U1
MUZ-HM15NA2
-
U1
HFC
utilized
R410A
NOTE:
RoHS compliant products have <G> mark on the spec name plate.
MUZ-HM24NA
PARTS CATALOG (OBB747)
SERVICE MANUAL
No. OBH747
REVISED EDITION-D
Indoor unit service manual
MSZ-HM•NA Series (OBH746)
CONTENTS
1. TECHNICAL CHANGES ···································3
2. PART NAMES AND FUNCTIONS ·····················4
3. SPECIFICATION ················································5
4. OUTLINES AND DIMENSIONS ······················10
5. WIRING DIAGRAM ··········································12
6. REFRIGERANT SYSTEM DIAGRAM ·············15
7. DATA ································································19
8. ACTUATOR CONTROL ···································32
9. SERVICE FUNCTIONS ···································33
10. TROUBLESHOOTING ·····································34
11. DISASSEMBLY INSTRUCTIONS ····················59
OBH747 REVISED EDITION-C is void.
Revision D:
• Capacity corrections have been corrected [7-1. 2), 3)].
OUTDOOR UNIT
